Hardware layout

The STM32F072 Discovery kit is designed around the STM32F072RBT6 microcontroller in
a 64-pin LQFP package.
Figure 2
LINK/V2, ST MEMS gyroscope I3G4250D, LEDs, push buttons, linear touch sensor, touch
keys, RF EEPROM connector and a USB Mini-B connector).
Figure 3
illustrates the connections between the STM32F072RBT6 and its peripherals (ST-
and Figure 4 help to locate these features on the STM32F072 Discovery board.

Figure 2. Hardware block diagram

STM32F072RBT6
I/O
LEDs
LD3 to LD6
I3G4250D
Linear touch
sensor
Mini-USB
Embedded
ST-LINK/V2
I/O
RESET
I/O
B2
RESET
B1
USER
Mini-USB
