SmartTouch2 Controller
The SmartTouch2 controller operates the movement
of the snowplow.
Figure 35
1. Lower/Float button
2. Left wing retract button
3. Left button
4. Left wing extend button
5. Raise button
•
On/Off switch—turns the plow controller on and off.
A green light illuminates when the controller is on.
Note:
Turn off the controller when not in use to
prevent accidental activation of the plow.
•
Raise button—raises the plow blade. Pressing the
button quickly twice automatically raises the blade.
•
Lower/Float button—lowers the plow blade
and activates the F
button quickly twice or holding it for 2 seconds
automatically lowers the blade and activates the
F feature, allowing the plow blade to follow
LOAT
the contour of the ground. A red light illuminates
when the F feature is active.
LOAT

Specifications

Blade width (wings retracted)
Blade width (wings expanded)
Blade height
Recommended push beam height
Weight
6. On/Off switch
7. Right wing extend button
8. Right button
9. Right wing retract button
feature. Pressing the
LOAT
•
Left button—angles the plow blade to the left
•
Right button—angles the plow blade to the right
•
Left wing extend button—extends the left plow
wing
•
Right wing extend button—extends the right plow
wing
•
Left wing retract button—retracts the left plow wing
•
Right wing retract button—retracts the right plow
wing
•
Sleep mode—If you do not use the controller for
20 minutes, it enters sleep mode and the controller
lights flash green and red. Turn off the controller
to deactivate the sleep mode.
g038785
Kickstand
Pull the kickstand spring pin to raise and lower the
kickstand.
1. Kickstand spring pin
22
Figure 36
2. Kickstand
2.44 m (96 inches)
3.05 m (120 inches)
76 cm (30 inches)
39.3 cm (15-1/2 inches)
440 kg (970 lb)
g033059
