4. Connect the blue plug from the headlight adapter
to the blue plug on the long wire harness
24).
5. Connect the free end of the headlight adapter to
the previously disconnected plug on the vehicle
wire harness (Figure
6. Repeat steps 1 through
headlight.
7. Continue the wire harness installation from step
5 of Installing the Wire Harness (page
For Four-Headlight Vehicles
1. Disconnect the wire harness plugs from the back
of the left vehicle headlights
1. Outer vehicle headlight
2. Headlight adapter
3. Inner vehicle headlight
4. Black plug
2. Connect the 2 ends of the headlight adapter to
the back of the left vehicle headlights
25).
3. Connect the black plug from the headlight
adapter to the long wire harness
4. Connect the blue plug from the headlight adapter
to the blue plug on the long wire harness
25).
5. Connect the free end of the headlight adapter to
the previously disconnected low-beam plug on
the vehicle wire harness
6. Grease, tuck, and secure the previously
disconnected high-beam plug on the vehicle
wire harness (Figure
Note:
You will not use this connector.
7. Repeat steps 1 through
headlights.
24).
5 on the right vehicle
13).
(Figure 25).
Figure 25
5. Blue plug
6. Headlight adapter
7. Vehicle low-beam plug
8. Vehicle high-beam plug
(Figure
(Figure
(Figure 25).
25).
6 on the right vehicle
8. Continue the wire harness installation from step
(Figure 5 of Installing the Wire Harness (page
Mounting the Plow
Controller
DANGER
The controller could cause serious injury if
contacted during a crash.
Mount the controller in a location where
vehicle occupants will not contact during a
crash.
Note:
Mount the controller in the cab in a dry area
where it does not interfere with vehicle operation or
visibility.
Important:
temperatures are below 16°C (60°F).
1. Determine the mounting location for the
controller.
2. Clean the location with the provided alcohol
wipe and dry it with a cloth or paper towel.
3. Clean the back of the swivel mount
with the alcohol wipe and then dry it.
g032933
1. Swivel mount
4. Remove the backing from 1 side of the adhesive
and apply it to the back of the swivel mount.
25).
5. Remove the remaining backing from the
(Figure swivel-mount adhesive and press the swivel
mount to the clean area of the dashboard for 30
seconds.
Important:
cannot remove it without destroying the
adhesive.
6. Clean the back of the controller with the alcohol
wipe and then dry it.
7. Remove the backing from 1 side of the adhesive
and apply it to the back of the mounting tab
(Figure
17
Do not install the swivel mount when
Figure 26
2. Mounting tab
Once the mount is placed, you
26).
13).
(Figure 26)
g032942
