SciCan STATCLAVE G4 Service Manual

Hide thumbs Also See for STATCLAVE G4:
Table of Contents

Advertisement

Quick Links

STATCLAVE G4 Service Manual
1.
UNIT OVERVIEW ............................................................................................................................................ 4
Introduction ...................................................................................................................................................... 4
Principles of operation ...................................................................................................................................... 4
Steps in a typical cycle ................................................................................................................................... 4
Diagram of key systems and components ........................................................................................................ 5
Front and back of the unit................................................................................................................................. 7
Top of the unit - inside reservoirs .................................................................................................................... 8
Specifications .................................................................................................................................................... 9
Safety devices .................................................................................................................................................... 9
Water supply ................................................................................................................................................... 10
Safety information .......................................................................................................................................... 10
Safe operation ................................................................................................................................................. 11
Safe servicing................................................................................................................................................... 11
Tools and hardware ........................................................................................................................................ 12
Shipping instructions ....................................................................................................................................... 13
2.
LOCATION AND INSTALLATION ................................................................................................................... 15
Unboxing, connecting and lifting the unit into position ................................................................................. 15
Checking package contents ............................................................................................................................. 17
Positioning a unit ............................................................................................................................................ 18
Unit dimensions and operating environment ................................................................................................. 18
Electrical connections and power ................................................................................................................... 19
Connecting the exhaust tubes ........................................................................................................................ 19
Direct to drain connection (recommended) ............................................................................................... 20
Connecting to a waste bottle ...................................................................................................................... 21
Connecting to the Internet ............................................................................................................................. 22
Connecting to a wired network................................................................................................................... 22
Connecting to a wireless network ............................................................................................................... 22
Connecting to an external water supply ......................................................................................................... 24
Connecting a Vista Pure Specialized Water Filtration System .................................................................... 24
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STATCLAVE G4 and is the answer not in the manual?

Questions and answers

Related Manuals for SciCan STATCLAVE G4

Summary of Contents for SciCan STATCLAVE G4

  • Page 1: Table Of Contents

    STATCLAVE G4 Service Manual UNIT OVERVIEW ............................4 Introduction ..............................4 Principles of operation ............................4 Steps in a typical cycle ........................... 4 Diagram of key systems and components ......................5 Front and back of the unit..........................7 Top of the unit – inside reservoirs ........................8 Specifications ..............................
  • Page 2 Connecting an auxiliary pump ........................25 FUNCTIONS AND CYCLES ..........................26 Touchscreen overview ............................ 26 System icons and what they mean ......................... 27 Unlocking the door – power on ........................29 Starting and stopping a cycle .......................... 30 Cycle chart and descriptions ........................... 31 Running a vacuum test ..........................
  • Page 3 FRONT AND DOOR COMPONENTS ......................97 RIGHT SIDE COMPONENTS .......................... 99 LEFT SIDE COMPONENTS .......................... 101 10. REAR COMPONENTS ..........................103 11. TOP COMPONENTS ........................... 105 APPENDIX A: STATCLAVE G4 plumbing diagram ....................107 APPENDIX B: STATCLAVE G4 electrical schematic .................... 108...

  • Page 4: Unit Overview

    1. UNIT OVERVIEW Introduction This service manual was created to act as reference for the service and repair of the STATCLAVE G4. If you have a question about the unit you are repairing, please do not hesitate to contact your local SciCan representative for information.

  • Page 5: Diagram Of Key Systems And Components

    Diagram of key systems and components...

  • Page 7: Front And Back Of The Unit

    Front and back of the unit 1. Venturi reservoir drain quick-connect 8. Touchscreen (OUT) 9. USB port 2. Warm air exhaust 10. Power cord input 3. Clean water reservoir drain quick-connect 11. Ethernet port (not visible) (OUT) 12. Auto fill port for clean water reservoir 4.

  • Page 8: Top Of The Unit - Inside Reservoirs

    Top of the unit – inside reservoirs Reservoir filters Venturi reservoir temperature sensor Venturi reservoir level sensors (max. and min.) Venturi recirculation tap Venturi reservoir Water cooling recirculation tap Clean water fill tap Clean water reservoir Clean water reservoir level sensors (empty and full) Clean water conductivity sensor...

  • Page 9: Specifications

    Specifications Width: 17.75” / 450 mm Machine Dimensions: Height: 19-19.5” / 483-495 mm Depth: 25” / 635mm Diameter: 11”/ 280 mm Chamber Dimensions: Depth: 15”/381 mm Sterilization Chamber Volume: 6.9 US gal / 26 L Distilled Water Reservoir Volume: 1 US gal / 4 L Venturi Reservoir Volume (including condenser): 1.6 US gal /6 L Weight (without water):...

  • Page 10: Water Supply

    High quality distilled water is recommended for use in the STATCLAVE G4. Deionized, demineralized or specially filtered water can also be used. Never use tap water. The STATCLAVE G4’s water conductivity sensor automatically reads the water quality and will not allow the unit to run a cycle unless the water quality is ≤...

  • Page 11: Safe Operation

    SciCan shall not be liable for incidental, special or consequential damages caused by any maintenance • or services performed on the STATCLAVE G4 by a third party or for the use of equipment or parts manufactured by a third party, including lost profits, any commercial loss, economic loss, or loss arising from personal injury.

  • Page 12: Tools And Hardware

    Reporting • It is vital for SciCan to learn of any problem in the field. This information will help SciCan solve the problem quickly and improve product reliability in new units. Biological waste • Waste water in the unit may contain biological contaminants; use a mechanical means to siphon the contents.

  • Page 13: Shipping Instructions

    Shipping instructions The unit should be serviced on site. If it is necessary to send the unit back to the dealer, follow these instructions: 1. Drain water from the unit. Follow these steps:...
  • Page 14 2. Remove residual water from the water cooling system. Follow these steps: Remove the Venturi water reservoir filter. Insert siphoning tool into each drainage hole and pull residual water from the system. 3. Screw in the leveling legs. 4. Specify upright, heated, and insured shipping. 5.

  • Page 15: Location And Installation

    2. LOCATION AND INSTALLATION The STATCLAVE G4 will require a support surface that is strong enough to hold the weight of a fully loaded unit with full reservoirs (a total operating weight of 175 lbs / 79.5 kg). The space should also allow room for the door to open correctly, for the top reservoir lids to be opened for filling and for ventilation on the right side.
  • Page 16 Open the bag and, with one person on either side, grip the strap handle and underside of the unit to lift and remove it from the base packaging. Unlatch the unit door to open it and remove items stored in the chamber. Check the contents. (See Checking package contents, in this section.) With the unit still on the floor, connect the power cord.

  • Page 17: Checking Package Contents

    Checking package contents...

  • Page 18: Positioning A Unit

    Positioning a unit Unit dimensions and operating environment...

  • Page 19: Electrical Connections And Power

    IMPORTANT: For the unit to function, BOTH reservoirs must be full and BOTH drain tubes must be connected. The STATCLAVE G4 uses water from the Venturi reservoir to generate vacuum draws at the beginning and end of each cycle. For the unit to operate, BOTH the clean water reservoir and the Venturi reservoir must contain the minimum required water levels.

  • Page 20: Direct To Drain Connection (Recommended)

    Direct to drain connection (recommended)

  • Page 21: Connecting To A Waste Bottle

    Connecting to a waste bottle...

  • Page 22: Connecting To The Internet

    Connecting to the Internet Connecting to a wired network Connecting to a wireless network...

  • Page 24: Connecting To An External Water Supply

    Connecting to an external water supply If you are connecting your STATCLAVE G4 to an external filling device such as a Vista Pure specialized water filtration system or external water tank and auxiliary pump, make sure your unit is set to the AUTOMATIC filling mode.

  • Page 25: Connecting An Auxiliary Pump

    Connecting an auxiliary pump...

  • Page 26: Functions And Cycles

    3. FUNCTIONS AND CYCLES The STATCLAVE G4 is a dynamic air removal (pre-vacuum) table-top steam sterilizer that uses steam to sterilize wrapped and unwrapped instrument loads typically used in dental and medical offices. It has six validated sterilization cycles with optimized drying for fast, effective instrument processing. An additional custom cycle can be configured using one of three temperature settings but this cycle must be validated by the user.

  • Page 27: System Icons And What They Mean

    System icons and what they mean The home screen contains four system icons. Press these icons to access additional functions and information.

  • Page 29: Unlocking The Door - Power On

    Unlocking the door – power on The STATCLAVE G4 will lock the chamber door when you select a cycle. To unlock the door, go to the home screen and follow these steps.

  • Page 30: Starting And Stopping A Cycle

    Starting and stopping a cycle...

  • Page 31: Cycle Chart And Descriptions

    Cycle chart and descriptions When selecting a sterilization cycle, users are instructed to choose according to the recommendations of leading infection control authorities and local regulatory guidelines.

  • Page 32: Running A Vacuum Test

    Test cycles Running a vacuum test The vacuum test checks the sterilizer’s plumbing system for leaks. Run this test with the rack and empty trays in the chamber. IMPORTANT: Vacuum tests must be conducted when the unit is cool. Running a vacuum test on a hot chamber may cause the test to fail.

  • Page 33: Running A Bowie-Dick Test

    Running a Bowie-Dick test The BOWIE-DICK test is used to ensure proper air removal is occurring in a pre-vacuum autoclave. Complete air removal is important because pockets of cool air remaining in the chamber can compromise sterilization. Using an FDA-approved Bowie-Dick test pack, the Bowie-Dick test runs a cycle at 134°C for 3.5 minutes to evaluate the correct air removal.

  • Page 34: What Happens During A Cycle

    What happens during a cycle The STATCLAVE G4, like all autoclaves, uses various combinations of time, temperature, and pressure to make up different cycles that are designed to sterilize specific load types. Each cycle is divided into various phases. Some cycles may have more or less phases depending on the needs of the load type. For example, a cycle for hollow instruments will have an additional vacuum draw phase before sterilization to ensure steam penetrates every hollow of every instrument in the load.
  • Page 35 Blower for Heat Exchanger: Cooling Pump: VVC: CLOSED 4. PRESSURE PULSE (phase included only on some cycles) Band Heaters: OFF (ON as required) Water Pump and VFB: ON as required Steam Generator: VDB: CLOSED VEC: OPEN Venturi Pump and VEV: Blower for Heat Exchanger: Cooling Pump: VVC:...
  • Page 36 Steam Generator: ON-OFF as required VDB: CLOSED VEC: CLOSED Venturi Pump and VEV: Blower for Heat Exchanger: Cooling Pump: VVC: CLOSED 8. VENTING Band Heaters: Water Pump and VFB: Steam Generator: VDB: OPEN VEC: CLOSED Venturi Pump and VEV: Blower for Heat Exchanger: Cooling Pump: VVC: CLOSED...

  • Page 37: Accessing And Reading Cycle Information

    Location and Installation section Connecting your STATCLAVE G4 to a network. The STATCLAVE G4 web portal is a direct connection to the STATCLAVE G4 on a user’s local area network. It is protected by the firewall and not accessible to outside users (unless they have a Remote Access Code. For more information, see Section below: Allowing a technician to access the STATCLAVE G4 from a remote location).

  • Page 38: Retrieving Cycle Information Using The Usb Data Back Up

    Retrieving Cycle Information Using the USB Data Back Up The USB storage device can be used to transfer cycle information stored in the unit to a computer. Best practice suggests this should be done once a week. To transfer data using the USB port, follow these steps: When the activity light on the USB storage device stops blinking or the USB icon on the LCD turns from a flashing green to a solid grey, remove the USB storage device and transfer the information to your computer.

  • Page 39: Adjusting Unit Settings

    Adjusting unit settings Using the user menu To access the user menu, select the SETTINGS icon from the home screen and then press on the image of the dentist. Menu item Submenu item What to do with it GENERAL Time Enter values Date Enter values...
  • Page 40 Enforced Select ON, OFF or DOCUMENTATION User Create User ID and PIN for up to 20 users SCREEN Screensaver Adjust the time delay for the screensaver LCD Contrast Adjust LCD readability Cycle Run Select circle or chart graphic to display during a cycle NETWORK SETUP Network Select WiFi or wired connection...
  • Page 41 Online Access Enter an email address to receive notifications Privacy Agree: Your unit will send cycle data and unit errors to SciCan. It will also receive automatic software updates to the user interface. Disagree: Your unit will NOT send any cycle information, but...
  • Page 42 Sterilization time Adjust the custom cycle’s sterilization hold time. Drying time Adjust the custom cycle’s drying time.

  • Page 43: Using The Service Menu

    Using the service menu To access the service menu, select the SETTINGS icon from the home screen, press on the image of the technician and enter the service code 7919 on the keypad. Menu item Submenu item What to do with it PRODUCTION TOOLS Calibration To calibrate the unit using a...
  • Page 44 Factory Default Reset all values to factory settings. DO NOT USE unless instructed by SciCan. NVRAM Tools NETWORK SETUP If your unit has access to the network but no internet, the connectivity icon on the home screen will be yellow. You may need to manually enter a DNS value, for example: 008.008.008.008. A static IP address may be required for some network configurations.

  • Page 45: Setting Up Load Traceability With User Id, Pin, And Process Enforced Usage

    The Process Enforced function keeps track of who has started and who has removed a load from your STATCLAVE G4. It does this by prompting users to enter a PIN at the start of a cycle, when they STOP or CANCEL a cycle, and when they REMOVE a load.
  • Page 46 To turn Process Enforced Usage ON, OFF or to activate DOCUMENTATION mode, select SETTINGS then USER and follow these steps:...
  • Page 47 Using Process Enforced Documentation mode: This mode activates the process enforced usage function along with the additional documentation function that generates a report with information about the cycle and the load type. When starting a cycle with Process Enforced Documentation mode turned ON, you will be prompted to identify the general contents of the load to be processed by selecting from a list as well as whether a biological indicator and chemical indicator are included.

  • Page 48: Setting Drying Time

    BI/Spore test results to the documentation report when these results are available. On the home screen, the STATCLAVE G4 will indicate a result is pending by showing this icon: Pressing this button will lead you to a screen that allows you to input the Biological Indicator results.

  • Page 49: Setting The Stand-By Mode

    STAND-BY LOW: For low to average use. Provides a balance between keeping the chamber at 70°C • and using a minimum of electricity. STAND-BY HIGH: For high use. Optimizes the STATCLAVE G4 for speed by keeping the chamber at • 120°C. This is the unit’s default setting.

  • Page 50: Registering For Online Access

    Registering for online access...

  • Page 51: First Start Up

    First start up...

  • Page 53: Maintenance

    WHEN A MAINTENANCE MESSAGE APPEARS, the user has 2 options: 1. Pressing OK to acknowledge the message. The user can then continue to use the STATCLAVE G4 or perform the required maintenance. When the user presses OK, the maintenance notification counter will restart the counter, regardless of whether or not the user has performed the maintenance.
  • Page 54 Replace the bacteriological filter Replace the door seal TECHNICIAN EVERY YEAR or 1,000 CYCLES A complete maintenance of the autoclave including testing of the pressure relief valve and the power failure pressure/vacuum relief valve (by a SciCan-approved technician) is recommended.

  • Page 55: Unlocking The Door - No Power

    Unlocking the door – no power The STATCLAVE G4 is equipped with a safety mechanism that automatically regulates the chamber pressure when the unit loses power. (The unit will take approximately 2 minutes to depressurize. Without power, the door lock will remain engaged.) CAUTION! Risk of Injury.

  • Page 56: Instructing A User To Provide Remote Access To A Unit

    Instructing a user to provide remote access to a unit Technicians and other authorized personnel may want to connect to your STATCLAVE G4 from a remote location to review its functioning or access stored information. To allow an external user to remotely access your STATCLAVE G4, you will need to provide a security token to the person requesting access.

  • Page 57: Cleaning The Chamber, Rack And Trays

    Cleaning the chamber, rack and trays IMPORTANT! When cleaning the chamber, be careful not to damage the temperature probe on the inside back wall of the chamber. Cleaning and disinfecting the external surfaces...

  • Page 58: Draining The Unit For Cleaning And Shipping

    Draining the unit for cleaning and shipping...

  • Page 59: Cleaning The Water Reservoirs And Reservoir Filters

    Cleaning the water reservoirs and reservoir filters Cleaning the external water reservoir tank 1. Disconnect the external tank from the sterilizer and close the tank valve. 2. Fill the tank with a solution of distilled water and alcohol (10%), such as isopropyl. 3.

  • Page 60: Cleaning The Chamber Filters

    4. Drain the tank and discard the solution. 5. Fill the tank with water and drain it, to remove any residual alcohol solution. 6. Reconnect the tank to the sterilizer and refill with distill water. Cleaning the chamber filters Over time the chamber’s three filters will collect enough debris to slow chamber draining and effect performance.

  • Page 61: Replacing The Bacteriological Filter

    Replacing the bacteriological filter Replacing the door seal...

  • Page 62: Annual Service Recommendations

    Annual service recommendations What to check Clean reservoirs and reservoir filters Check integrity of incoming and outgoing services (power, water supply, drain) Check general condition of machine Check bacteriological filter (replace if required) Inspect and clean right cover air filter Check door seal (replace if required) Inspect chamber filters (replace if required) Review error history...
  • Page 63 WARNINGS AND PRECAUTIONS If you have questions about the unit you are repairing, please do not hesitate to contact your local SciCan representative for information. Also, the unit is heavy. Exercise caution and seek assistance when lifting or carrying it.

  • Page 64: Calibration Procedure

    Calibration reference meters (temperature and pressure) are important for accurately setting the • STATCLAVE G4 unit so that the correct sterilization conditions (temperature and pressure) occur in accordance with the original specifications of the unit and national/international standards. Any digital thermometer and temperature probe (thermocouple) used during calibration should have the •...

  • Page 65: How To Calibrate The Unit

    Druck DPI 705R Absolute Pressure Meter with external 0 - 7 bar absolute pressure transducer with • ¼” NPT female thread For measuring Temperature and Pressure combined Heise PTE-1 Handheld LCD digital calibrator complete with temperature and pressure modules, and PT100 probe as follows: •...
  • Page 66 Side test port plug 3. Check that the calibration fitting (01-115514S) is equipped with the correct pressure port for your reference meter. The calibration fitting comes with a quick connect pressure port (A) but you can remove this and replace it with either the 1/4-inch knurled nut pressure port (B) for 1/4-inch Teflon tubing or the 3/8-inch knurled nut pressure port (C) for 3/8-inch Teflon tubing.
  • Page 67 9. Connect one end of the pressure meter tube to your reference meter. 10. Connect the other end of the pressure meter tube to the pressure port on the calibration fitting. STAGE 2. Starting calibration 11. From the STATCLAVE G4 home screen, access the calibration function by following these steps:...
  • Page 68 Enter 7919 press EN icon Press Press Calibration Calibration once to lock again to the door. START. STAGE 3. Adjusting the atmospheric pressure 12. When you press the Calibration button to start the calibration cycle, the following screen will appear. IMPORTANT! When this screen appears, the POA field will be highlighted and you will have 30 seconds to complete the POA calibration before the cycle continues to the vacuum phase.
  • Page 69 To complete the POA calibration, compare the pressure reading on the display (P) with the pressure reading on the pressure reference meter. (See the following Step for a full explanation of the calibration screen.) Adjust the pressure reading using the up or down arrows on the POA offset field. NOTE: The difference in two readings should be within 0.5Kpa.
  • Page 70 NOTE: The POV offset will be adjusted again at Step 26 of the calibration process when the unit reaches a pressure (vacuum) value in the region of 20kPa (30kPa or less). 17. On completion of the vacuum phase, the unit will go back to atmospheric pressure. Check the readings between the unit’s pressure display (P) and the pressure reference meter.
  • Page 71 If your values DO NOT match the values, stop the procedure, tighten all the calibration fittings and start a new calibration. STAGE 6. Adjusting the unit pressure and temperature 21. Wait until the cycle reaches the sterilization phase (temperature above 132°C). 22.

  • Page 72: How To Back Up The Calibration Data

    30. After removing the calibration fitting, install a new test plug to close the test port. Open the door and switch off the unit. Calibration is now complete. How to back up the calibration data To back-up the calibration data (which is saved automatically) for future references using the Backup NVRAM feature, follow these steps: Power the unit OFF.

  • Page 73: Diagnostics And Troubleshooting

    Using the device screen The STATCLAVE G4 has a number of sensors and systems that are constantly reading and generating values. These sensors and systems can be seen on the device screen, a diagnostic tool found in the service menu.
  • Page 74 The device screen is divided into four groups (see image below). Section A is for monitoring all systems. The values displayed here are generated in real time. Section B is for checking the heating systems. To verify the functioning of either the steam generator (TSG) or the top and bottom band heaters (TBHT and TBHB), you can use the arrows to the right to increase the temperature in that component to a specific target temperature and then watch the corresponding reading in Section A to see if the component successfully reaches the target temperature.
  • Page 76 WARNINGS AND PRECAUTIONS If you have questions about the unit you are repairing, please do not hesitate to contact your local SciCan representative for information. Also, the unit is heavy. Exercise caution and seek assistance when lifting or carrying it.

  • Page 77: Investigating A Leak: How To Perform A Positive Pressure Test

    Investigating a leak: how to perform a positive pressure test There are 3 methods to pressurize the system with air to search for leaks in the plumbing system. Method 1 uses the air intake tube, method 2 uses the test port and method 3 uses a solenoid valve. Method 1: Using the air intake tube 1.

  • Page 78: Method 2: Using The Test Port

    10. When the leak test is complete, press the VDB button on the device screen to release the air from the chamber. 11. Reconnect the silicone tubing to the biological air filter. 12. Unlock the door using the lock icon on the device screen. Method 2: Using the test port For this test, you will need a test port fitting with Teflon tubing to connect your compressed air regulator to the test port.
  • Page 79 5. Insert your regulator and pressurize the chamber to 25 psig (270 kPa gauge). NOTE: the door will automatically lock when the unit senses the chamber pressure rising. When the pressure in the chamber has reached its target, close the regulator valve and turn the unit OFF.

  • Page 80: Step-By-Step Troubleshooting By Symptom

    STERILE and CYCLE FAULT operation. next solution. messages. A power outrage or power NOTE: STATCLAVE G4 units connected fluctuation occurred while to the Internet and registered with the unit was in operation. SciCan will automatically send Cycle Fault messages to SciCan’s international service center.
  • Page 81 Make sure that the printer cable is connection failure. connected securely with the connector on the back of the STATCLAVE G4. Make sure that the printer is powered ON. Power OFF the STATCLAVE G4 for 10 seconds and then power it ON again.
  • Page 82 PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Touchscreen shows: [Internet Unit is not connected to An X over the connectivity icon means Internet. the unit is not connected to a network. If it is supposed to be connected to a network and the X is visible, it is because the unit is unable to acquire an IP address.
  • Page 83 Spam filter is blocking emails Ensure that you have accepted the SciCan Privacy policy by putting a check mark in the box on the CONTACTS page of your web portal. Door will not open – no power...
  • Page 84 Water is pooling under the unit There is a leak in the system. Contact your SciCan dealer. Bowie-Dick test has failed Attempt a second Bowie-Dick test. If it fails, contact your SciCan dealer. No cycles are stored in the Logic board configuration Check unit serial number to see if it unit’s memory...

  • Page 85: Troubleshooting Loading Errors And Operator Complaints

    Troubleshooting loading errors and operator complaints COMPLAINT POSSIBLE CAUSE POSSIBLE SOLUTION Machine will not start, and Clean water reservoir issue Press on the icon to confirm touchscreen shows: [H2OX] either water level is too low or whether it is a water level water used is of inadequate problem or a water quality quality.
  • Page 86 COMPLAINT POSSIBLE CAUSE POSSIBLE SOLUTION Instruments do not dry. Improper loading NOTE: For optimal drying, allow the cycle to continue to Wrong cycle selection for this completion. particular load Make sure the instruments are Chamber draining issues loaded correctly in the chamber.
  • Page 87 COMPLAINT POSSIBLE CAUSE POSSIBLE SOLUTION Inadequate water quality. Drain the clean water reservoir and refill it with high-quality distilled water. Organic or inorganic residues on Instruments must be free of the instruments. debris prior to sterilization. Clean and rinse all instruments before loading them into the sterilizer.
  • Page 88 COMPLAINT POSSIBLE CAUSE POSSIBLE SOLUTION Door will not close Item obstruction Check for instrument or a cassette that is keeping the door from closing correctly. Check the door seal to make sure it is properly seated. To re- seat the door seal, see Section 9.13 Replacing the Door Seal.

  • Page 89: Cycle Fault List

    Cycle Fault List CF # Description Possible causes Phase of the cycle CF 4 Chamber failed to Chamber door seal leak VACUUM PULSE achieve sterilization Boiler heater element conditions Water Pump PRESSURE PULSE Valve Exhaust Chamber (132/134°C cycle) Valve Vent Chamber PRESSURE PULSE (121°C cycle) PRESSURIZING...
  • Page 90 CF # Description Possible causes Phase of the cycle CF 28 Chamber pressure went Pressure measurement failure. above threshold Check pressure transducer Miscalibration. Blocked exhaust / valve CF 30 Actual chamber Air leak PRESSURIZING temperature and Blocked exhaust / valve calculated chamber Miscalibration temperature do not...
  • Page 91 CF # Description Possible causes Phase of the cycle CF 54 Measured pressure Pressure and/or temperature sensor STERILIZATION LESS than calculated miscalibration. pressure at Unable to generate steam, or there is a 205 kPa (for 121°C cycle) leak in the system. CF 55 Measured pressure Pressure sensor miscalibration.
  • Page 92 CF # Description Possible causes Phase of the cycle CF 73 Vacuum draw timeout Possible air leaks due to tubing and/or VACUUM DRAW Unit failed to reach stuck valves before STERI vacuum target Valve Exhaust Chamber VACUUM DRAW Valve Drain Boiler before STERI (R&P Water Pump Venturi cycle)
  • Page 93 CF # Description Possible causes Phase of the cycle CF 83 Bottom band heater Bottom band heater temperature temperature sensor sensor failure failure Controller board failure CF 84 Venturi water reservoir Venturi water reservoir temperature temperature sensor sensor failure failure Controller board failure CF 90 Corrupted/not...

  • Page 94: Removing And Replacing Panels

    WARNINGS AND PRECAUTIONS If you have questions about the unit you are repairing, please do not hesitate to contact your local SciCan representative for information. Also, the unit is heavy. Exercise caution and seek assistance when lifting or carrying it.

  • Page 95: Removing And Reinstalling The Left Panel

    Removing and reinstalling the left panel 1. Remove the 2 screws. 2. Slide the panel to the rear to disengage the tabs at the top and bottom of the panel. Remove X 2 Figure 6.1-1 Removing and reinstalling the right panel 1.

  • Page 96: Removing And Reinstalling The Back Panel

    Removing and reinstalling the back panel 1. Use the condenser service port to completely drain the condenser. 2. Loosen the 2 screws in keyhole slots. 3. Remove the 4 other screws. 4. Lift the panel and use the steel cable to hang it in the service position. 5.

  • Page 97: Front And Door Components

    7. FRONT AND DOOR COMPONENTS Figure 7-1 ITEM PART # PART NAME INVENTORY DESCRIPTION Fascia-Decal Kit 01-115437S LCD Fascia WIFI Adaptor Kit 01-114711S WiFi antenna (not visible) 01-113682S Speaker (not visible) Speaker Assembly Chamber door adjustment screw (factory set) Chamber door adjustment locking screw 01-115452S Door lock mechanism assembly...
  • Page 98 ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115425S Door handle Door Handle 01-115453S Door locking solenoid (not visible) Solenoid Latching 01-115546S Door locked microswitch (not visible) Door Latching Microswitch 01-115545S Door closed microswitch (not visible) Microswitch W/Roller 01-115408S USB port (not visible) Cable, Extension USB 01-115438S LCD touchscreen...

  • Page 99: Right Side Components

    8.RIGHT SIDE COMPONENTS Figure 8-1 ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115413S I/O board IO PCB, STATCLAVE 01-115408S USB port Cable, Extension USB, STATCLAVE 01-115546S Door latch microswitch Door Latching Microswitch 01-115403S Heat exchanger Heat Exchanger 01-112024S Power switch Rocker Switch Spare Kit...
  • Page 100 ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115404S Blower Air Blower 120V 01-115405S Blower Air Blower 230V 01-115468S Solenoid valve VDB – drain Valve Drain Boiler Kit, STATCLAVE steam generator 01-110505S EMI filter EMI Filter 20A/250V 01-115467S Solenoid valve VEC – exhaust Valve Exhaust Chamber Kit chamber 01-115470S...

  • Page 101: Left Side Components

    9. LEFT SIDE COMPONENTS Figure 9-1 ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115399S Venturi device (not visible) Venturi Water Jet Kit, STATCLAVE 01-115392S Condenser check valve Check Valve, Barb, AF, No Spg 01-115401S Water cooling pump Water Cooling Pump Comp, STATCLAVE 01-115393S Steam generator...
  • Page 102 ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115400S Venturi pump Venturi Water Pump Comp, STATCLAVE 01-115392S Vacuum check valve Check Valve, Barb, Af, No Spg 01-115385S Test port Fitting, Sprint Plug Flush, G1/4 01-115469S Solenoid valve VVC – vacuum Valve Vent Chamber Kit, STATCLAVE relief 01-115471S Solenoid valve VEV –...

  • Page 103: Rear Components

    REAR COMPONENTS ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115448S Clean water reservoir float Float Sensor, Reservoir, STATCLAVE switches (full and empty) 01-115449S Clean water reservoir Sensor Conductivity, STATCLAVE conductivity sensor 01-108567S Pressure transducer Pressure Transducer 68 PSI 01-115385S Test port Fitting, Sprint Plug Flush, G1/4 01-115397S Steam generator water pump...
  • Page 104 ITEM PART # PART NAME INVENTORY DESCRIPTION Steam generator switch – Steam Generator Switch – Level (Part safety (part of SG kit) of SG Kit) 01-110505S EMI filter EMI FILTER 20A/250V 01-115434S External fill port Bulkhead Connector, 1/4", STATCLAVE 01-115431S Condenser water Coupling barb, 3/8”...

  • Page 105: Top Components

    11. TOP COMPONENTS ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115447S Reservoir cooling spout Rubber Spout Kit, STATCLAVE 01-115446S Venturi recirculation spout Venturi Silicone Tube, STATCLAVE 01-115448S Venturi water reservoir float Float Sensor, Reservoir, STATCLAVE switch, high 01-115448S Venturi water reservoir float Float Sensor, Reservoir, STATCLAVE switch, low 01-115451S...
  • Page 106 ITEM PART # PART NAME INVENTORY DESCRIPTION 01-115480S Reservoir filters Reservoir Filter (1 Pcs), STATCLAVE 01-115438S LCD fascia assembly Fascia LCD Kit, STATCLAVE 01-115449S Clean water reservoir Sensor Conductivity, STATCLAVE conductivity sensor 01-115448S Clean water reservoir float Float Sensor, Reservoir, STATCLAVE switch, empty 01-115448S Clean water reservoir float...

  • Page 107: Appendix A: Statclave G4 Plumbing Diagram

    APPENDIX A: STATCLAVE G4 plumbing diagram...

  • Page 108: Appendix B: Statclave G4 Electrical Schematic

    APPENDIX B: STATCLAVE G4 electrical schematic...

Table of Contents

Save PDF
