Command access MLRK1 Insert Instructions page 4

4
Once the Motor Link is installed securely on the Dogging Tab. Line up the two Mounting Holes.
Mounting Holes
5
With one hand holding the motor in place, flip the bar over and secure the kit by installing the two
provided screws into the Mounting Holes from the backside of the bar.
Mounting Holes
6
To reinstall the Filler Plate, you will first need to remove the plastic Pad Guide.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
installation instructions
Filler Plate
Pad Guide
4
# 2 0 6 2 2 _ A
