Command access MLRK1 Insert Instructions page 3

1
Slide Filler Plate off the bar.
2
If the Dogging Assembly is installed, remove its two screws and discard.
3
To install the motor, place the Motor Link Cutout over the Dogging Tab.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
installation instructions
Filler Plate
Motor Link Cutout
Dogging Tab
3
# 2 0 6 2 2 _ A
