Steering wheel control extra settings (Cont)
Dual assignment legend
1. Not allowed 6. ATT/Mute
2. Not allowed 7. Preset-Up
3. Seek-Up/Next 8. Preset-Down
4. Seek-Down/Prev 9. Power
5. Mode/Source 10. Band
* Not applicable in this application

Resetting the AX-GMCL2-SWC

1. With the radio on, turn the potentiometer:
Note: Before proceeding, remember the position the potentiometer is at.
Left......hold for 3 seconds
Right.....hold for 3 seconds
Left......hold for 3 seconds
Back to the initial position
2. The L.E.D. inside the interface will turn off for a couple seconds, then flash fast, then flash slowly
(up to (16) times, indicating which radio is connected to the interface), and then turn off. Pay
close attention as to how many slow flashes there are. This will help in troubleshooting, if need
be. Refer to the L.E.D. feedback section for more information.
3. Within a few seconds the L.E.D. will turn on, and the radio will turn off.
4. Within a minute the L.E.D. will turn off, and the radio will come back on, indicating the resetting
and initialization process was successful.
Axxess Integrate
®
Installation instructions for part AX-GMCL2-SWC
11. Play/Enter
12. PTT
13. On-Hook
14. Off-Hook
15. Fan-Up *
®
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
IMPORTANT
If you are having difficulties with the
installation of this product, please call our
Tech Support line. Before doing so, look over
the instructions a second time, and make
sure the installation was performed exactly
as the instructions are stated. Please have
the vehicle apart and ready to perform
troubleshooting steps before calling.
