COMMAND & COMMUNICATION GUIDE
ICR 803
Bar Code Scanner

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICR 803 and is the answer not in the manual?

Questions and answers

Related Manuals for SICK ICR 803

Summary of Contents for SICK ICR 803

  • Page 1 COMMAND & COMMUNICATION GUIDE ICR 803 Bar Code Scanner...

  • Page 2: Table Of Contents

    Table of Contents Introduction……………………………………………………………………………..3 Serial Programming ...................... 3 Conventions ........................3 Menu Command Syntax....................3 Query Commands ......................4 Tag Field Usage ....................... 4 SubTag Field Usage ....................4 Data Field Usage...................... 4 Concatenation of Multiple Commands..............4 Responses ........................4 Examples of Query Commands .................

  • Page 3: Introduction

    Introduction This manual details the communication structure and commands used to send programming parameters to the ICR803. To get started please refer to the manual named “ICR803 QUICK START GUIDE”. Serial Programming The serial programming commands may be used in place of the programming bar codes.

  • Page 4: Query Commands

    Query Commands Several special characters can be used to query the device about its settings. What is the default value for the setting(s). What is the devices current value for the setting(s). What is the range of possible values for the setting(s). The devices response uses a dash (-_ to indicate a continuous range of values.

  • Page 5: Examples Of Query Commands

    When responding, the device echoes back the command sequence with the status character inserted directly before each of the punctuation marks (the period, exclamation point, comma, or semicolon) in the command. Examples of Query Commands Description Command Response This query requests the range of possible cbrena*.

  • Page 6: Resetting The Standard Product Defaults

    Activate Serial Trigger SYN T CR Deactivate Serial Trigger SYN U CR When the Trigger Command is activated, the imager scans until a bar code has been read, until the deactivated command is sent, or until the serial time out has been reached.

  • Page 7: Menu Commands

    Menu Commands Selection Setting (* indicates Serial Command Description default) Factory Default Settings Default Defalt Terminal Interfaces Terminal ID TERMID### 300 BPS 232BAD0 600 BPS 232BAD1 1200 BPS 232BAD2 2400 BPS 232BAD3 Baud Rate 4800 BPS 232BAD4 9600 BPS 232BAD5 19200 BPS 232BAD6 38400 BPS...
  • Page 8 High* HLCIDL1 Output Selections Image VGA IMGVGA0 IMGVGA1 BEPBEP0 Beeper – Good Read BEPBEP1 BEPLVL0 Beeper Volume – Good Read BEPLVL1 Medium* BEPLVL2 High BEPLVL3 Beeper Pitch – Good Read Low (1600) (min 400Hz) BEPFQ11600 Frequency Medium (3250Hz)* BEPFQ13250 High (4200Hz) max9000Hz BEPFQ14200 Beeper Duration –...
  • Page 9 Hands Free Timeout Range 0-300,000ms TRGPTO###### LED Power Level PWRLDC0 Low (50%) PWRLDC50 High (100%)* PWRLDC100 Illumination Lights Lights On* SCNLED1 Lights Off SCNLED0 Imager Timeout Range 0 – 999,999ms SDRTIM###### 200 milliseconds SCNDLY200 Aimer Delay 400 milliseconds SCNDLY400 Off* (no delay) SCNDLY0 SCNAIM0 Aimer Mode...
  • Page 10 Working Orientation ROTATN1 Rotate Clockwise 90 Upside Down ROTATN2 ROTANTN3 Rotate Counterclockwise 90 Prefix/Suffix Selections Add CR Suffix to All Symbologies VSUFCR Add Prefix PREBK2## Prefix Clear One Prefix PRECL2 Clear All Prefixes PRECA2 Add Suffix SUFBK2## Suffix Clear One Suffix SUFCL2 Clear All Suffixes SUFCA2...
  • Page 11 Codabar Check Character Validate, But Don’t Transmit CBRCK21 Validate, and Transmit CBRCK22 Codabar Concatenation CBRCCT0 CBRCCT1 Require CBRCCT2 Codabar Message Length Minimum (2-60)*4 CBRMIN## Maximum (2-60)*60 CBRMAX## Code39 Default All Code 39 C39DFT Code 39 C39ENA0 C39ENA1 Code39 Start/Stop Char Don’t Transmit* C39SSX0 Transmit...
  • Page 12 Code 93 Default all code 93 settings C93DFT Code 93 C93ENA0 C93ENA1 Minimum (0 – 80) *0 C93MIN## Code 93 Message Length Maximum(0-80) *80 C93MAX## Code 93 Code Page C93DCP Code 2 of 5 Default all code 2 of 5 settings R25DFT Code 2 of 5 Off*...
  • Page 13 TELENA1 Telepen Outpt AIM Telepen Output TELOLD0 Original Telepen Output TELOLD1 Telpen Message Length Minimum(1-60)*1 TELMIN## Maximum(1-60)*60 TELMAX## UPC-A Default All UPC-A Settings UPADFT UPC-A UPAENA0 UPAENA1 UPC-A Check Digit UPACKX0 UPACKX1 UPC-A Number System UPANSX0 UPANSX1 UPC-A 2 Digit Addenda Off* UPAAD20 UPAAD21...
  • Page 14 2 Digit Addenda Off * UPEAD20 5 Digit Addenda On UPEAD51 5 Digit Addenda Off UPEAD50 UPC-E1 Off* UPEEN10 UPEEN11 EAN/JAN-13 Default All EAN/JAN Settings E13DFT EAN/JAN-13 E13ENA0 E13ENA1 EAN/JAN-13 Check Digit E13CKX0 E13CKX1 EAN/JAN-13 Check Digit 2 Digit Addenda On E13AD21 2 Digit Addenda Off* E13AD20...
  • Page 15 Validate Type 10 and transmit MSICHK1 MSI Message Length Minimum (4-48)*4 MSIMIN## Maximum(4-48)*48 MSIMAX## Plessey Code Default All Plessey Settings PLSDFT Plessey Code Off* PLSENA0 PLSENA1 Plessey Message Length Minimum (4048)*4 PLSMIN## Maximum (4048)*48 PLSMAX## RSS-14 Default All RSS-14 Settings RSSDFT RSS-14 RSSENA0...
  • Page 16 Code 16K Default All Code 16K Settings 16KDFT Code 16K Off* 16LENA0 16LENA1 Code 16K Msg. Length Minimum (0 – 160)*1 16KMIN### Maximum (0 – 160)*160 16KMAX### Code49 Default All Code 49 Settings C49DFT Code49 C49ENA0 C49ENA1 Code49 Msg. Length Minimum (1-81)*1 C49MIN## Maximum(1-81)*81...
  • Page 17 Off* CANENA0 Kix (Netherlands) Post KIXENA1 KIXENA0 Australian Post AUSENA1 Off* AUSENA0 Japanese Post JAPENA1 Off* JAPENA0 China Post Default All China Post Settings CPCDFT China Post Off* CPCENA0 CPCENA1 China Post Msg. Length Minimum (0-80)*4 CPCMIN## Maximum (0-80)*80 CPCMAX## Korea Post Default all Korea Post KPCDFT...
  • Page 18 Aztec Code Msg. Length Minimum (1-3750)*1 AZTMIN#### Maximum(1-3750)*3750 AZTMAX#### Aztec Runes Enable Runes AZTRUN1 Disable Runes* AZTRUN0 SYMBOLOGIES Default All OCR Settings OCRDFT OCR-A OCRENA1 OCR-B OCRENA2 US Currency On OCRENA3 MICR E 13 B On OCRENA4 SEMI Font OCRENA5 All OCR Off* OCRENA0 Enter OCR Template...
  • Page 19 IMAGE SHIP COMMANDS Image Ship *Infinity Filter - Off IMGINF0 Infinity Filter - On IMGINF1 *Compensation Off IMGCOR0 Compensation On IMGCOR1 *Pixel Depth - 8 bits/pixel (grayscale) IMGBPP8 Pixel Depth - 1 bit/pixel (B&W) IMGBPP1 *Don’t Sharpen Edges IMGEDG0 Sharpen Edges (0-23) IMGEDG## *File Format - JPEG IMGFMT6...

  • Page 20: Sample Bar Codes

    Sample Bar Codes The table of sample bar codes below may be used for testing purposes of the ICR803. The ICR803 user needs to ensure the appropriate menu option is turned on inside the ICR803 to successfully decode the images below. CODE 128 CODE 39 DataMatrix...
  • Page 21 MaxiCode Menu 7, 11 MicroPDF417 Commands 7, 11 Aimer Australian Orientation Aztec Code PDF417 Baud Rate Plessey Code Beeper PosiCode British Post Postnet Canadian Post Prefix Centering Presentation China QR Code Codabar Query Codablock F Responses Code 11 RS232 Data Bits Code 128 RS232 Handshaking Code 16K...
  • Page 22 Menu Command Syntax Reading Menu Commands Reset Defaults Plug and Play Scanview RS232 Configuring USB COM Port Emulation Serial Programming USB HID Trigger Commands Query Commands ICR803 Command & Communication Guide Rev A – 04/2007...
  • Page 24 Phone +81 (0)3 3358 1341 E-Mail support@sick.jp Nederlands Phone +31 (0)30 229 25 44 E-Mail info@sick.nl Norge More representatives and agencies Phone +47 67 81 50 00 in all major industrial nations at E-Mail austefjord@sick.no www.sick.com SICK AG | Waldkirch | Germany | www.sick.com...
