InSTALLATIOn

AC Mains
90~264 Vac
47~63 Hz
1 or 3 ph.
Required
Motor
Regen
Resistor
(Optional)
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Internet: http://www.copleycontrols.com
Xenus XTL
Required
for CE
Line Filter
Edge Filter
(Optional)
+24 Vdc
Power
Supply
Required
™
for BRUSHLESS/BRUSH MOTORS
CME 2
RS-232
(DTE)
CAN
Master
Controller
or
PLC
Quad A/B
Encoder
Tel: 781-828-8090
DIGITAL SERVO DRIVE
RoHS
ASCII
Control
CAN
Node(s)
Sin/Cos
Resolver
Encoder
-S -R
Models Models
