- Page 1 Adam Equipment GC INDICATOR P.N. 3056610550, Revision C6, August 2010) Software Rev 2.18 and up Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010...
- Page 2 Easy Reference: Model name of the indicator/scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place: © Adam Equipment Company 2010...
-
Page 3: Table Of Contents
USING “0000” TO ENTER THE CALIBRATION PARAMETER ..31 12.2 USING “2006” TO ENTER THE SERVICE PARAMETERS ..33 13.0 REPLACEMENT PARTS AND ACCESSORIES ......39 14.0 SERVICE INFORMATION ............... 41 15.0 WARRANTY INFORMATION ............44 © Adam Equipment Company 2010... - Page 4 © Adam Equipment Company 2010...
-
Page 5: Introduction
• The indicators include automatic zero tracking, audible alarm for pre-set counts, automatic tare, pre-set tare, an accumulation facility that allows the count to be stored and recalled as an accumulated total. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010... -
Page 6: Specifications
14°F - 104°F Power supply 230 VAC 50/60 Hz 12VDC @ 800ma adaptor for CKa type units. Battery Internal rechargeable battery Calibration Automatic External Display 3 x 6 digits LCD digital displays Indicator ABS Plastic Housing © Adam Equipment Company 2010... - Page 7 Parts counting, weighing, accumulating memory, pre-set count with alarm Interface RS-232 bi-directional interface English, German, French, Spanish selectable text Date/Time Real Time Clock (RTC), To print date and time information (Dates in year/month/day, day/month/year or month/day/year formats- Battery backed) © Adam Equipment Company 2010...
-
Page 8: Installation
Avoid air movement such as from fans or • opening doors. Do not place near open windows or air-conditioning vents. Keep the scales clean. Do not stack material on • the scales when they are not in use. © Adam Equipment Company 2010... - Page 9 © Adam Equipment Company 2010...
-
Page 10: Connection
4 wire load cell, 1B uses a 6 conductor cable to go from the indicator to the platform or load cell where it connects to the 4 wires from the load cells. The Excitation and sense wires are connected internally in the GC indicator. © Adam Equipment Company 2010... -
Page 11: Key Descriptions
Entering a value using the keypad will store that as the tare value. [Zero] Sets the zero point for all subsequent weighing to show zero. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010... -
Page 12: Displays
The LCD design is: WEIGHT UNIT WEIGHT COUNT WEIGHT DISPLAY It has 6-digit display to indicate the weight on the scale. Net Weight Display, "Net" Stability indicator, symbol Zero indicator, 0 symbol The weighing unit: kg, lb © Adam Equipment Company 2010... -
Page 13: Unit Weight Display
• The Lo, OK, Hi symbols will be used when the preset count has been set. • The symbol “Mem” will be seen when the internal memory has a record of previous weighings stored in it. © Adam Equipment Company 2010... -
Page 14: Operation
• When the container is removed a negative value will be shown. If the scale was tared just before removing the container, this value is the gross weight of the container plus all products those were removed. © Adam Equipment Company 2010... -
Page 15: Parts Counting
[Smpl] key. • The number of units will be displayed on the "Count" display and the computed average weight will be shown on the "Unit Weight" display. © Adam Equipment Company 2010... - Page 16 6.3.3 Check-counting • Check-counting is a procedure to cause an alarm to sound when the number of items counted on the scale meets or exceeds a number stored in the memory by using the [Pst] key. © Adam Equipment Company 2010...
- Page 17 2 seconds. • To clear the memory- first press [MR] to recall the totals from memory and then press the [CE] key to clear all values from the memory. 6.3.6 Automatic Accumulated Totals © Adam Equipment Company 2010...
- Page 18 • See the Section 9.0 on RS-232 Interface for details on how to enable Automatic Accumulation. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010...
-
Page 19: User Parameters
• The first parameter is “F1” “CAL”. (See section 8.0 for details) • To enter into Calibration function, press the [Tare] key. • To exit a parameter, press the [Zero] key. • To select the second parameter press the [U. Wt./Units] key. © Adam Equipment Company 2010... -
Page 20: Setting Of Pin
[Tare] key to go to the next weighing unit. The weighing units selected will depend upon the model and the capacity of the scales. See Section 12.2, Service Parameters. • Press the [Zero] key to return to the weighing mode. © Adam Equipment Company 2010... -
Page 21: Calibration
• Remove the weight. The scale will return to normal weighing. • If an error message “SPAn” “FAIL” is displayed, then repeat the process. • After calibration, the scale should be checked whether the calibration is correct. If necessary, repeat calibration. © Adam Equipment Company 2010... - Page 22 NOTE: GCa scales will have the lb or kg indicator on, to show the unit of the weight requested. If the scale was in pounds before starting the calibration, the weights requested will be in pound values or if the scale was weighing in kilograms then metric weights will be requested. © Adam Equipment Company 2010...
-
Page 23: Rs-232 Interface
Pin 5 Signal Ground The scale can be set to print text in English, French, German or Spanish. See the RS- 232 parameters section for details. All lines end with line feed <lf>, and carriage return <cr>characters. © Adam Equipment Company 2010... - Page 24 <lf><cr> Data Format- Memory Recall Print: <lf><cr> DATE 12/09/2006 TIME 14:56 <lf><cr> ------------------ TOTAL 1.234 Kg 10 pcs Includes 1 line feed <lf><cr> ------------------ 2 line feeds, carriage return <lf><cr> <lf><cr> © Adam Equipment Company 2010...
- Page 25 Weight per unit counted Stck. Piezas Number items counted Anzhl Num. Number weighings added subtotals Total Total Gesamt Total Total weight count printed Date Date Datum Fecha Print date Time Heure Zeit Hora Print time © Adam Equipment Company 2010...
-
Page 26: Input Commands Format
Will display the current accumulated memory and print the total results. C<cr><lf> Same as pressing [MR] first and then the [CE] key to erase the current memory. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010... -
Page 27: Rs-232 Setup
Print Auto continuous printing, print Print mAn automatically or printing manually. AC Auto Select the operation of AC mAn accumulating AC oFF automatically, manually or turned off. EnGLiS LAnG EnGLiS Select Language FrEnCH printing. GErMAn SPAniS © Adam Equipment Company 2010... - Page 28 Print continuously and Print continuously , accumulate accumulate when [M+] is [M+] and [Print] key Cont to PC automatically when pressed, [Print] key no have no function stable , [Print] key function no function © Adam Equipment Company 2010...
-
Page 29: Real Time Clock Setup
• Press the [Tare] key to accept the chosen format and then enter the date in this format. “dAtE” “m-d-y” “051209” note current date is in current format, will show 000000 if no date has been set. • Press the [Tare] key to accept the date. © Adam Equipment Company 2010... -
Page 30: Auto Sleep Function
• The battery should be charged for at least 12 hours for full capacity. • Just above the “Unit Weight” display is an LED to indicate the status of © Adam Equipment Company 2010... -
Page 31: Backlight For Lcd
Press the [Tare] key to store the value or press the [Zero] key to escape from this setting and return to weighing. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010... -
Page 32: Error Codes
Damaged Load cell. Damaged Electronics. diSPEr Shows when a number The accumulated totals for weight is too large tot fit the or count exceed 999999. The data display on RS232 is still shown accurately © Adam Equipment Company 2010... -
Page 33: Service Parameters
The parameters available are: “F1” To enter the Calibration “CAL” “F2” “Pin” To set a new Pin number for access “F3” “Unit” Enable Weighing Units © Adam Equipment Company 2010... - Page 34 Press the [U.Wt./Units] key to change the value. Press [Tare] to • accept the displayed setting and go to the next unit. • Press the [Zero] key to return to the menus. Press the [Zero] key again to return to normal weighing. © Adam Equipment Company 2010...
-
Page 35: Using "2006" To Enter The Service Parameters
Press the [Tare] key to enter a parameter. To exit a parameter, press • the [Zero] key. The Weight window will show the parameter number and the Unit • Price and Count windows will show the word describing the function. © Adam Equipment Company 2010... - Page 36 (kg), grams (g) or pounds (lb) for USA sales and kilogram or grams for the rest of the world. • Press [Tare] to accept the displayed value. © Adam Equipment Company 2010 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com...
- Page 37 • Press the [U.Wt./Units] key to change the value. The indicator will determine what the minimum and maximum increment is possible for the capacity and decimal point you have set. • Press [Tare] to accept the displayed value. 12.2.4 F4 -CALIBRATION © Adam Equipment Company 2010...
- Page 38 12.2.6 F6 -RE-ZERO RANGE • To enter this parameter, press the [Tare] key when “F6” is shown. • The display will show the current re-zero range. • Press the [U.Wt./Units] key to change the value. © Adam Equipment Company 2010...
- Page 39 • To enter this parameter, press the [Tare] key when “F9” “Pin” is shown. • The “Weight” display will show “Pin 1” • Enter the new password. The “Unit Weight” display will show dashes. Press [Tare]. © Adam Equipment Company 2010...
- Page 40 • The display will show the current setting, i.e. “ 0.5d “ resenting one-half a division. Other possible settings are 1d, 2d, 4d and Off. • Press the [U.Wt./Units] key to change the value. Press [Tare] to accept the displayed value. • Press [Zero] to return to weighing. © Adam Equipment Company 2010...
-
Page 41: Replacement Parts And Accessories
13.0 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier or Adam Equipment. A partial list of such items is as follows- • Main Power cord • In use cover • Power supply (GC-a) •... - Page 42 © Adam Equipment Company 2010...
-
Page 43: Service Information
In order to provide further assistance, the supplier will need the Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010... - Page 44 Include any recent history of the unit. For example: -Has it been working since it’s delivered -Has it been in contact with water -Damaged from a fire -Electrical Storms in the area -Dropped on the floor, etc. ready: © Adam Equipment Company 2010...
- Page 45 © Adam Equipment Company 2010...
-
Page 46: Warranty Information
This product may include a rechargeable battery that is designed to be removed and replaced by the user. Adam Equipment warrants that it will provide a replacement battery if the battery manifests a defect in materials or workmanship during the initial period of use of the product in which the battery is installed. - Page 47 WARNING: This product includes a sealed lead-acid battery which contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Adam Equipment products have been tested with, and are always supplied with mains power adaptors which meet all legal requirements for the intended country or region of operation, including electrical safety, interference and energy efficiency.
- Page 48 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com © Adam Equipment Company 2010...
