Summary of Contents for Adam GBK Mplus Series
- Page 1 Adam Equipment GBK Mplus / GFK Mplus Series...
- Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place:...
-
Page 4: Table Of Contents
SCALE PARAMETERS ..................36 13.4 PERCENT WEIGHING AND ANIMAL WEIGHING ........... 37 14.0 ERROR MESSAGES ............... 38 15.0 REPLACEMENT PARTS AND ACCESSORIES ......39 16.0 SERVICE INFORMATION ..............40 17.0 WARRANTY INFORMATION ............41 18.0 APPENDIX ..................42 © Adam Equipment Company 2020... -
Page 5: Introduction
• OIML Approved models, GBK/GFK-Mplus, only allow “Kg” and “g” as units, have calibration controlled by jumpers or passcodes and other limitations as noted in the manual. © Adam Equipment Company 2020... -
Page 6: Specifications
300mm x 520mm x 660mm / 11.8” x 20.5” x 26” (w x d x h) Net Weight 7.4kg Features Weighing, Check Weighing, Parts counting, Check Counting, Animal Weighing, Accumulating memory Interface RS-232 bi-directional interface English, German, French, Spanish, Italian and Portuguese selectable text © Adam Equipment Company 2020... - Page 7 400 mm x 620 mm x 860 mm (w x d x h) 12.5kg Net Weight Weighing, Check Weighing, Parts counting, Check Counting, Animal Features Weighing, Accumulating memory Interface RS-232 bi-directional interface English, German, French, Spanish, Italian and Portuguese selectable text © Adam Equipment Company 2020...
-
Page 8: Installation
Avoid air movement such as from fans or opening doors. Do not place near open windows or air- conditioning vents. • Keep the scales clean. Do not stack material on the scales when they are not in use. © Adam Equipment Company 2020... -
Page 9: Setting Up The Scales
• If the scale is an approved version, GBK/GFK-Mplus, and the Calibration Counter has been enabled (see section 6) the current values will be displayed. These values should match the values marked on the scale at the time of verification, if it has been verified. © Adam Equipment Company 2020... -
Page 10: Keypad
% in percent weighing [Low It sets the limits for check weighing and None Limit] allows setting of either the low limit or the high limit or both. & [High Limit] © Adam Equipment Company 2020... - Page 11 [1] to [0] Allow entering numerical values where and [CE] required, setting of limits, tare value, time and date for example. © Adam Equipment Company 2020...
-
Page 12: Display
When in Check Weighing mode, the LCD backlight colour will change to help identify when the weight is below, within or over the limits. Weight LCD colour below the low limit Amber Within the limits Green © Adam Equipment Company 2020... -
Page 13: Calibration Counter For Approved Scales
The battery symbol will scroll to indicate it is charging, it may take several hours to fully charge the battery from empty. • When the battery is charged to full capacity, the battery symbol will stop scrolling and it will show as fully charged © Adam Equipment Company 2020... -
Page 14: Backlight
• The scale has an automatic re-zeroing function to account for minor drifting or accumulation of material on the platform. However, you may need to press [Zero] to re-zero the scale if small amount of weight is still shown when the platform is empty. © Adam Equipment Company 2020... -
Page 15: Taring
The zero indicator will also be on as the platform is back to the same condition it was when [Zero] was pressed last. Press [Tare] or [Zero] to remove the tare value and display zero. The Net indicator will disappear. © Adam Equipment Company 2020... -
Page 16: Weighing
• Either place 10 parts on the platform for determining the average piece weight or use a different number of parts. For example, place 20 parts on the platform, press [CE] to clear the last values and then enter the value 20 using the numeric keypad. © Adam Equipment Company 2020... - Page 17 The [Tare] key works normally during this time, so it is possible to tare the display with a container on the platform • During parts counting the display can be changed to show the net weight, unit weight and number of parts by each time pressing the [Func] key. © Adam Equipment Company 2020...
-
Page 18: Check-Weighing
The limits can be locked by the manager. A Limit Password must be used to change the limits or recall other limits from memory. 3. If Limit Password is enabled then enter the password which will allow you to change the limits or the operation of the beeper. © Adam Equipment Company 2020... -
Page 19: Setting Up While Weighing
2. To disable the check weighing function, enter zero into both the limits as described above. When the current limits are shown, press [CE] to clear the settings, then press [Tare] to store the zero values. © Adam Equipment Company 2020... -
Page 20: Limits Storing And Recalling
9) to be recalled. “rEC X” will be displayed for 2 seconds indicating the values stored in the location “X” is being recalled. The scale will change to the recalled limits, weighing units and settings for the beeper bar graph. © Adam Equipment Company 2020... -
Page 21: Percent Weighing
• Press [Tare] again to enter percent weighing. The scale will set the sample mass on the platform as 100% reference weight. NOTE: If there is no reference weight on the platform and percent weighing function is entered, pressing [Tare] again will return the indicator to normal weighing. © Adam Equipment Company 2020... - Page 22 • Press [Unit] to return to normal weighing. NOTE: The display may jump by large numbers unexpectedly if small weights are used to set as 100% reference. The scale checks if the weight is too small and will show Error 8. © Adam Equipment Company 2020...
- Page 23 [Func] key then press the [Tare] key to accept it. • The display will flash “Ani“ 2 times then show the current weight, 0.00. The scale is now ready to weigh. © Adam Equipment Company 2020...
-
Page 24: Animal Weighing Procedure
2. The accumulated weights will be stored in either kg or g, depending upon the weighing unit in use. 3. If at any time the weighing units are changed, the accumulated data will be lost. © Adam Equipment Company 2020... -
Page 25: Manual Accumulation
• To print the total, press [Print] to recall and then immediately press [Print] the second time to print the results. • To erase the memory, press [Print] to view the total and then immediately press [CE] to clear the memory. © Adam Equipment Company 2020... -
Page 26: Automatic Accumulation
In all cases the display must return to zero or a negative number, before another sample can be added to the memory. More products can be added and [Print] be pressed again for up to 99 entries until the capacity of display is exceeded. © Adam Equipment Company 2020... -
Page 27: Rs-232 Specification
9 pin d-sub miniature socket Pin 3 Output Pin 2 Input Pin 5 Signal Ground The scale can be set to print text in English, French, German, Spanish, Italian or Portuguese See the RS-232 parameters section for details. © Adam Equipment Company 2020... - Page 28 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> Net Wt. (or Gross Wt.) Net Wt. 1.234 kg <cr><lf> Unit Wt. 123 g <cr><lf> g 10 pcs <cr><lf> <cr><lf> <cr><lf> © Adam Equipment Company 2020...
- Page 29 Data Format- Continuous Output- Normal weighing: Net Weight (or Gross wt.) 1.234 kg <cr><lf> <cr><lf> <cr><lf> Data Format- Continuous Output- Parts Counting: Net Weight (or Gross wt.) 1.234 kg <cr><lf> U.W. 123 g <cr><lf> 10 pcs <cr><lf> <cr><lf> <cr><lf> © Adam Equipment Company 2020...
- Page 30 Zeit Hora Hora Print time Scale ID Bal ID Waagen ID Bal ID ID Bil ID Bal Scale ID number User ID Util ID Nutzer ID Usuario ID ID Utiliz ID Utiliz User ID Number © Adam Equipment Company 2020...
-
Page 31: Input Commands Format
The GBK/GFK-Mplus approved bench scales models are sealed to prevent unauthorised calibration. Contact Adam Equipment or your supplier for more details. WARNING: CALIBRATION OF THE SCALES MAY MAKE IT ILLEGAL TO USE THE SCALES FOR SALES OF GOODS. CONTACT YOUR TRADING STANDARDS OFFICE FOR FURTHER ASSISTANCE. -
Page 32: Parameter Settings
• Press [Func] to scroll through the parameters and press [Tare] to enter a parameter setting. • Press [Func] to view the options for setting. • Press [Tare] to confirm the change and then advance to the next parameter by pressing the [Func] key. © Adam Equipment Company 2020... - Page 33 1. The Check weighing password is separate from the scale password, see section 13.3. If the password is other than 0000, user must enter the password to gain access to “F1 LLk”, “F2 bEP”, “F3 CPS” “F4 nCK”. © Adam Equipment Company 2020...
-
Page 34: Rs-232 Parameters
The user can also set a Scale ID number and a User ID number. Parameter Description Options Default Values or setting C1 on Prt on Prt on Enable or disable the RS-232 interface Prt oFF C2 bd 1200 4800 Baud Rate 2400 4800 9600 19200 38400 57600 115200 © Adam Equipment Company 2020... - Page 35 CoPY 1 to CoPY 8 CoPY 1 Number of copies per print C10 LF none to 9 LFCr 1 LFCr Number of lines feed after each print Scale will perform the following, depending on the Accumulation and Print Settings: © Adam Equipment Company 2020...
-
Page 36: Scale Parameters
SLP 5 SLP 10 00:00:00 S4 dt Set Time and Date format Enter the time manually and settings Enter the date manually mm:dd:yy S5 diS Display all weights or only when stable StAb © Adam Equipment Company 2020... -
Page 37: Percent Weighing And Animal Weighing
This parameter allows the user None Enabled to enter the Percent weighing always Function. See Section 10.7. P2 Ani Enter the Animal Weighing Set the filter value. Enabled mode of operation, See section Always 10.8 © Adam Equipment Company 2020... -
Page 38: Error Messages
Electronics is damaged. Err 19 Weight lower limit is larger than High limit is set first, then the low limit is set upper limit higher than the high limit and low limit not equal to zero. © Adam Equipment Company 2020... -
Page 39: Replacement Parts And Accessories
Weight below scale range 15.0 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier or Adam Equipment. A partial list of such items is as follows- • Main Power cord or adaptor for USA versions. -
Page 40: Service Information
Include any recent history of the unit. For example: -Has it been working since it’s delivered -Has it been in contact with water -Damaged from a fire -Electrical Storms in the area -Dropped on the floor, etc. © Adam Equipment Company 2020... -
Page 41: Warranty Information
The warranty will cease to operate if the equipment is not returned in the original packaging and with correct documentation for a claim to be processed. All claims are at the sole discretion of Adam Equipment. This warranty does not cover equipment where defects or poor performance is due to misuse,... -
Page 42: Appendix
C8 LAb COMP (Complete) Decimal point CoMM Label report SIMP (Simple) S9 AZ oFF, 0.25, 0.5 C9 CPY CoPY (1 - 8) AutoZero Tracking Number of Copies S10 rE Battery recharge status P a g e © Adam Equipment Company 2020... - Page 43 WARNING: This product includes a sealed lead-acid battery which contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Adam Equipment products have been tested with, and are always supplied with mains power adaptors which meet all legal requirements for the intended country or region of operation, including electrical safety, interference and energy efficiency.
- Page 44 © Copyright by Adam Equipment Co. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
