The following document contains information on Cypress products. The document has the series
name, product name, and ordering part numbering with the prefix "MB". However, Cypress will
offer these products to new and existing customers with the series name, product name, and
ordering part number with the prefix "CY".
How to Check the Ordering Part Number
1.
Go to www.cypress.com/pcn.
2.
Enter the keyword (for example, ordering part number) in the SEARCH PCNS field and click
Apply.
3.
Click the corresponding title from the search results.
4.
Download the Affected Parts List file, which has details of all changes
For More Information
Please contact your local sales office for additional information about Cypress products and
solutions.
About Cypress
Cypress is the leader in advanced embedded system solutions for the world's most innovative
automotive, industrial, smart home appliances, consumer electronics and medical products.
Cypress' microcontrollers, analog ICs, wireless and USB-based connectivity solutions and reliable,
high-performance memories help engineers design differentiated products and get them to market
first. Cypress is committed to providing customers with the best support and development
resources on the planet enabling them to disrupt markets by creating new product categories in
record time. To learn more, go to www.cypress.com.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cypress F2MC-16FX Series
Summary of Contents for Cypress F2MC-16FX Series
- Page 1 The following document contains information on Cypress products. The document has the series name, product name, and ordering part numbering with the prefix “MB”. However, Cypress will offer these products to new and existing customers with the series name, product name, and ordering part number with the prefix “CY”.
- Page 2 MB96670 Evaluation Board 16-bit Microcontroller MC-16FX Family Operation Manual Doc. No. 002-04759 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): +1 408.943.2600 www.cypress.com...
- Page 3 Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
- Page 4 Preface This document indicates directions for use about the "MB96670 evaluation board" which is the evaluation environment of MB96670 series of a F MC-16FX-16bit microcontroller *1: Referred to MCU below. Using the product safely This manual contains important information for using this product safely. Be sure to read this manual before using the product, and to follow the directions given in this manual in order to use the product correctly.
- Page 5 Preface Caution of the product described in this manual The following precautions apply to the product described in this manual. Indicates a potentially hazardous situation which could result in death or serious injury and/or a fault in the user's system if the product is not used correctly. WARNING Before performing any operation described in this manual, turn off all the power supplies to the system.
-
Page 6: Table Of Contents
Contents Overview ..................................6 Functional overview ............................... 7 Block diagram ................................ 9 Functional Details ................................ 10 Power supply settings ............................10 Sub clock settings ..............................11 UART ch.0 select jumper ............................. 13 Mode SW settings ............................... 14 OCD (On chip debugger) interface ........................15 Other jumper settings ............................ -
Page 7: Overview
1. Overview The MB96670 Evaluation Board provides the evaluative environment of the MB96670 series MCU Figure 1. MB96670 Evaluation Board MB96670 Evaluation Board Operation Manual, Doc. No. 002-04759 Rev. *A... -
Page 8: Functional Overview
Overview 1.1 Functional overview This board can mount MCU (with or without socket). The location of the main function is shown as follows. Figure 2. MB96670 Evaluation Board functional overview RS/USB monitor Main Main/Sub xtal connector (solder side) xtal Mode monitor monitor socket... - Page 9 Overview Table 1. MB96670 Evaluation Board function list Function Specification Remarks with socket MB96F670 NQPACK064SD-ND with socket or direct mounted HQPACK064SD Main clock 4MHz Oscillator with socket Sub clock 32.768kHz External power supply External power supply connection connection (DC3.3V to 5.0V) OCD debugger(MB2100-01-E) OCD connector Connection...
-
Page 10: Block Diagram
Overview 1.2 Block diagram The block diagram of this board is shown below. Figure 3. MB96670 Evaluation Board Block Diagram OCD connector 4MHz Main board DC12V→ · DC5V 5.0V 32kHz · DC3.3V 3.3V MODE SW (MB96670) RS ch.0 Monitor USART ch.0 With land Socket 64... -
Page 11: Functional Details
2. Functional Details The functional details of this board are shown as following. 2.1 Power supply settings Please confirm the following jumpers are closed. (J2, J3, J4, J5, J14) Figure 4. Power supply jumpers location AVCC AVSS VCC_MCU DVCC AVRH MB96670 Evaluation Board Operation Manual, Doc. -
Page 12: Sub Clock Settings
Functional Details Table 2. Power supply jumpers function Jumper Function Setting [VCC_MCU] Close (default): ON Power supply for VCC pin Open: OFF [AVRH] Close (default): ON Power supply for AVRH pin Open: OFF [DVCC] Close (default): ON Power supply for DVCC pin Open: OFF [AVCC] Close (default): ON... - Page 13 Functional Details Table 3. J7 setting Setting X1A connection select X1A connect to sub clock (default) X1A connect to Q41 Table 4. J24 setting Setting X0A connection select X0A connect to GND X0A connect to sub clock (default) X0A connect to Q40 MB96670 Evaluation Board Operation Manual, Doc.
-
Page 14: Uart Ch.0 Select Jumper
Functional Details 2.3 UART ch.0 select jumper The connection destination of the UART ch.0 signal can be selected by J20/J21. These jumpers location and settings are shown below. Figure 6. UART ch.0 select jumper location From right to left 1, 2, 3 J20:TX , J21:RX Table 5. -
Page 15: Mode Sw Settings
Functional Details 2.4 Mode SW settings The selection of the operational mode of MCU can be set by SW1 as follows. The mode switch location and settings are shown below. Figure 7. Mode SW location Mode SW bit1:MD , bit2:DEBUG MB96670 Evaluation Board Operation Manual, Doc. -
Page 16: Ocd (On Chip Debugger) Interface
MB96670 : user mode (default) 2.5 OCD (On chip debugger) interface The MB96670 evaluation board can operate software "Softune" for debugging by connecting Cypress OCD-E (on chip debugger). The OCD connector location and settings are shown below. Figure 8. OCD cable connect location connector MB96670 Evaluation Board Operation Manual, Doc. -
Page 17: Other Jumper Settings
Functional Details Figure 9. How to connect OCD-E Please turn the coaxial cable appended to Cypress OCD-E(MB2100-01-E) as shown in a left chart. 2.6 Other jumper settings These jumpers in the table can control the connection between the MCU pin and the peripheral I/O. -
Page 18: Signal Monitor
Functional Details 2.7 Signal monitor The correspondence of the monitor land and the MCU pin number is shown as follows. (Q numbers are equal to MCU pin numbers.) Table 8. Monitor land list Pin No. Pin No. Pin No. MB96670 Evaluation Board Operation Manual, Doc. No. 002-04759 Rev. *A... -
Page 19: Main Board Connection
Functional Details 2.8 Main board connection The connection of MCU and I/O on the main board is shown below. General-purpose LED The correspondence table for the general-purpose LED mounted on the main board and the MCU pin number is shown below. - Page 20 Functional Details NMI SW The correspondence of NMI SW mounted on the main board and the MCU pin number is shown below. Table 11. NMI switch MB96670 NMI SW Parts number Pin number Pin name Reset SW The correspondence of RESET SW mounted on the main board and the MCU pin number is shown below. Table 12.
-
Page 21: Power - On
3. Power - ON Basically, this board cannot turn on the power supply alone. Please mount on the main board(MB2198-760-E) and use it. 3.1 FOR TEST USE ONLY, External power supply connection pin The external power supply connection position is shown as follows. (VCC = 3.3V to 5.0V) When you connect an external power supply to this pin, and you use alone this board, please short-circuit J22 (DVCC) and J23 (AVCC). -
Page 22: Circuit Diagram
4. Circuit Diagram MB96670 Evaluation Board Operation Manual, Doc. No. 002-04759 Rev. *A... -
Page 23: Additional Information
5. Additional Information For More information, please visit our websites: http://www.cypress.com/products/mb96670 http://www.cypress.com/products/16fx Please contact your local support team for any technical question. MB96670 Evaluation Board Operation Manual, Doc. No. 002-04759 Rev. *A... -
Page 24: Recycling
6. Recycling Valid for European Union Countries: According to the European WEEE-Directive and its implementation into national laws we take this device back. For disposal please send the device to the following address: Cypress Semiconductor Pittlerstrasse 47 63225 Langen GERMANY... -
Page 25: China-Rohs Regulation
7. China-RoHS regulation 中華人民共和国「電子情報製品汚染防止管理弁法」の対応 Compliance with Administration on the Control of Pollution Caused by Electronic Information Products Of the People’s Republic of China 这标记是按照2006年2月28日公布的[电子信息产品污染控制管理办法]以及SJ/T11364-2006[电 子信息产品污染控制标识要求]在中国销售的电子信息产品的环保使用期限。如遵守关于这产品 的安全或使用上的注意，在这期限内(从生产日期起算)不会因产品中的有害物质漏到外部、或 发生突然变异，而引起环境污染和对人体或财产的重大影响。 产品 中 有 毒 有 害 物 质或元素的名称及含量 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬... -
Page 26: Revision History
Document Title: MB96670 Evaluation Board 16-bit Microcontroller F MC-16FX Family Operation Manual Document Number: 002-04759 Revisio #ECN Issue Date Origin of Description of Change Change 02/28/2013 TETY Initila release 5255479 06/01/2016 TETY Migrated to Cypress format MB96670 Evaluation Board Operation Manual, Doc. No. 002-04759 Rev. *A...
