12

EXTERNAL SENSOR SELECTION

If an external sensor is connected, the
The external sensor can be used for:
1, control according to the room temperature - the sensor is located in the room ( - - - option)
2, control according to the fl oor temperature - the sensor is located in the fl oor (- - - option)
- - - If connected, the external sensor measures the temperature at the place of its installation
(suitable, for example, for places at which the thermostat cannot be located, yet you want to
control according to this room);
3, maximum fl oor temperature monitoring - the sensor is located in the fl oor (selection of 15 to 99,5°C)
15...99,5°C If connected, the external sensor monitors the fl oor temperature; the maximum
temperature allowed for fl oor heating must be set
temperature, with simultaneous fl oor temperature monitoring).
If the preset limit temperature is exceeded, the thermostat is switched off irrespective of the room
temperature, and the "EXT SENS STOP" message appears on the LCD. The heating device is switched
on again if the external sensor temperature drops by 0.5 °C.
If the external sensor is unconnected or faulty, the "EXT SENS ERROR" message appears on the LCD.
Set the external sensor option by turning the "
tEL nO

PHONE NUMBER SETTING

Allows the following options:
1) TO SENdER = SMS will be sent back to the telephone number from which the message was sent.
2) TO ANOTHER NR = SMS will be sent back to the telephone number entered in the thermostat.
3) bOTH NUMbERS = SMS will be sent back to both telephone numbers (combination options 1 and 2).
When choosing 2) and 3) option we enter a phone number n the international format (420123456789),
to which return SMS messages on the thermostat condition should be sent. Is possible to enter a phone
number min. 10-digit to 15-digit.
Turning the " " button, enter the phone number stepwise; confi rm each setting with the "
13

PIN CODE SETTING

Enter the PIN code of the SIM card inserted in the thermostat.
Turning the " " button, enter 4 digits stepwise; confi rm each setting with the "
14

GSM TEST

After setting the PIN code of the SIM card inserted in the thermostat is performed to test the GSM
module and PIN validation.
Turning the " " button to start test of GSM module and checking of PIN code.
The" " button displays the next constant,; pushing "
Checking the
GSM module.
15 RELAY TEST
Testing the correct connection the thermostat to boiler (this function is identical with the TEST mode
in the main menu).
Start the test by turning the "
messages appear on the LCD). The "
the main menu.
( - - - set by default)
symbol appears on the LCD (to approx. 2 minutes).
" button and press the "
" you return to the main menu.
PIN entered
correctly.
" button. The output relay is switched on/off several times (the ON/OFF
" button displays the next constant; pushing "
ON
(control according to the room
" button to confi rm.
" button.
INSERT SIM
SIM card not inser-
ted. Insert the SIM
card, disconnect
power to the 5 s,
make adjustment
and repeat test.
" you return to
OFF
12 EXT SENSOR
12 EXT SENSOR
EXT SENS STOP
TO SENdER
TO ANOTHER NR
" button.
420000000000---
13 ENTER PIN
14 GSM TEST
ERROR PIN
Wrong PIN.
Reset PT32GST
and enter PIN
again.
15 RELAY TEST
7
