- Page 1 Manual ref. 4608 – 17 Version: Date: 14/03/2017 Wood burning stove VICKY 5 ref. 1340505 Documentation provided for the user and installer...
-
Page 2: Technical Specifications
Foreword: You have purchased a Franco Belge wood burning stove, we thank you for your custom. This stove has been carefully developed, designed and manufactured in France to provide complete satisfaction. It is essential to read this manual carefully before a registered heating engineer installs your stove. -
Page 3: Installer Instructions
INSTALLER INSTRUCTIONS The installation of this appliance must comply with all local regulations, including those referring to National and European Standards before it can be operated. However, for England and Wales, only, the coming into force on 1st April 2002 of SI 2002 No 440 exempts the householder from this legal requirement for the installation of solid fuel fired appliance whose rated heat output is 50kW or less in a building having no more than 3 storeys (excluding any basement) if a Competent Engineer is employed who is registered under the Registration Scheme for Companies and Engineers involved in the Installation and Maintenance of Domestic Solid Fuel Fired Equipment operated by... - Page 4 CONNECTION TO THE CHIMNEY FLUE The flue should be connected to the appliance and must comply with all local and national regulations. They especially depend on the type of flue, its thermal resistance and its temperature class. Example of a connection to the chimney flue. General connection rules for a flue using the rear exit option.
- Page 5 USER INSTRUCTIONS • Before using the appliance, read the instructions and recommendations carefully. • The appliance must be operated in accordance with these instructions, failure to do so can cause damage to the stove. • Never obstruct the air intakes. •...
-
Page 6: Lighting And Adjusting
LIGHTING AND ADJUSTING When you light the stove for the first time it should only be a small fire as all the materials must be given time to adapt to the effects of heat. The paint finish will be fully hardened after the stove has been used, and the door should be opened very carefully as there may be a risk that the door rope gasket will stick to the paint. -
Page 7: Ash Removal
Step 4 Light the firelighters and close the door on the stove. The fire will slowly increase so warming the flue gradually without producing copious amounts of smoke and as the fire grows so does the flue draught to remove any smoke. Leave it alone until the top of the stove feels warm to the touch, about 5 to 10 minutes, then close the primary air (under grate air see page 4). -
Page 8: Chimney Cleaning
SPARE PARTS If, after many years, some parts need to be replaced, contact your stove supplier, or any other company who distribute the Franco Belge stoves. Give them the information on the stoves IDENTITY PLATE or on the WARRANTY CARD, which should be kept safely, even after the warranty has expired. -
Page 9: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST N° Description Coding N° Description Coding INT. Ø125 Spigot 1 4312 3721 - 53 Air regulation control face 1 4122 388112 - 000 Cleaning hatch (125) 1 4230 3721 - 53 Ash-box 1 3316 388112 096 Fire dog 1 0306 387101 –... - Page 10 To remove the baffle lift it upwards and pull forward. Drop the rear edge downwards and then lower the whole baffle into the stove and remove through the door. In order to continuously improve its products, FRANCO BELGE. reserves the right to modify its appliances without prior notice. LIABILITY Remember that the manufacturer’s liability is limited to the product as sold.
- Page 11 Have your appliance serviced by a qualified heating engineer once per year. Servicing your stove should not be seen as a chore but rather the means to getting the most efficient use and increasing the life of the stove. A badly maintained stove will run inefficiently, so you will burn more fuel, and if left unmaintained for a period could seriously damage the component parts within the stove which will then need replacing.
