Monte Carlo
Document n°1291-8
22/03/2011
Wood stove
NF EN 13240 : 2001 - EN 13240/A2 : 2005
Model : 134 12 07
Technical manual
Output : 11,5 kW
to be saved
by the user
for future reference
Rue Orphée Variscotte
Description of the appliance
59660 MERVILLE
Téléphone : 03 28 43 43 22
Installation instructions
Fax : 03 28 43 43 60
Operating instructions
Subject to modifications.
Spare parts
Warranty certificate
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FRANCO BELGE MONTE CARLO 134 12 07
Summary of Contents for FRANCO BELGE MONTE CARLO 134 12 07
-
Page 1: Wood Stove
Monte Carlo Document n°1291-8 22/03/2011 Wood stove NF EN 13240 : 2001 - EN 13240/A2 : 2005 Model : 134 12 07 Technical manual Output : 11,5 kW to be saved by the user for future reference Rue Orphée Variscotte Description of the appliance 59660 MERVILLE Téléphone : 03 28 43 43 22... -
Page 2: Table Of Contents
FRANCO BELGE, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 80-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products. -
Page 3: Product Information
Monte Carlo - réf. 134 12 07 This appliance is meant to burn wood safely WARNING Incorrectly installed, this appliance can be dangerous and possibly cause serious accidents. We recommend that you engage the services of a professional engineer for its installation and the regular maintenance requirements 1. -
Page 4: Installation Instructions
Monte Carlo - réf. 134 12 07 2. Installation instructions 2.1 Warning to the user ventilation gratings. Floor and walls : Make sure there are not combustible All the local and national regulations, and or covered with combustible material. in particular those relating to national and Otherwise it must necessary to install a non- European standards, must be observed when combustible protection. -
Page 5: Chimney Connector
Monte Carlo - réf. 134 12 07 1 - Flue collar 1 - Flue collar 2 - Ceramic 2 - Ceramic rope rope 3 - Blanking 3 - Blanking plate plate 4 - Clamp 4 - Clamp 5 - Screw 5 - Screw (5 x 30) (5 x 30) -
Page 6: Pre-Utilisation Check
Monte Carlo - réf. 134 12 07 stovepipe, and the flue, must be leak tight. be swept several times per year, together with the - For the premises equipped with a mechanical stovepipe connection section. controlled ventilation, the airtightness has to prevent the exhauster drawing out the smokes from the If the chimney catches fire, you must cut off the flue draught, close the doors and windows,... -
Page 7: Instructions For User
Monte Carlo - réf. 134 12 07 3. Instructions for user • Recommended fuel : Wood The manufacturer will not be responsible for Use hard wood logs, which have been cut for at least damages on parts of the appliance due to the use two years and stored, under shelter. -
Page 8: Maintenance Of The Chimney
3.4. Cleaning re-sprayed / touched up using a stove paint. These products are available from your Franco Belge Dealer. It is essential to keep the grate free from a heavy build up of ashes. -
Page 9: Trouble Shooting
Monte Carlo - réf. 134 12 07 3.8. Trouble Shooting : This sign means that you should ask for a qualified engineer to do the work. Problem Probable causes - ACTION Fire difficult to start Wood green, too damp or poor - Use the recommended fuel. - Page 10 Monte Carlo - réf. 134 12 07 Notes Technical manual "1291"...
-
Page 11: Spare Parts
Monte Carlo - réf. 134 12 07 4.Spare parts When ordering spare parts, specify the stove type and serial number, including the colour index (on the guarantee or identification plate), the name of the part and the part number. Example : Wood stove "Monte Carlo”, ref. 134 12 07, color Y, top plate 352177 EF A = 134 12 07 Y ;... - Page 12 Monte Carlo - réf. 134 12 07 Figure 8 - Stove - exploded view Technical manual "1291"...
- Page 13 Monte Carlo - réf. 134 12 07 A = 134 12 07 Y ; B = 134 12 07 L ; C = 134 12 07 B ; D = 134 12 07 E ; E = 134 12 07 P ; F = 1341207 C N°...
- Page 14 E P C Color : Serial number : ..........• This certificate has to be completed and kept carefully. In case of claims, send a copy of this to : FRANCO BELGE BP 73, 59660 MERVILLE, FRANCE.
