Technical Manual
Montfort Elegance
Montfort Mk2 EA
Wood burning stove
Model : 134 05 02
Nominal output : 5 kW
THIS APPLIANCE CAN BE INSTALLED IN UK SMOKE
CONTROL AREAS ONLY USING WOOD FUEL
Description of the appliance
Installation instructions
Operating instructions
Warranty certificate
EN 13240
Spare parts
Document n°1300-5 - 20/03/2012
Technical manual
to be saved
by the user
for future reference
Parc d'activités de la Verte Rue
Allée des Prêles
59270 BAILLEUL
Tél. : 03 28 40 32 50
Matériel sujet à modifications
sans préavis.
Document non contractuel.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FRANCO BELGE 134 05 02
Summary of Contents for FRANCO BELGE 134 05 02
- Page 1 Montfort Elegance Document n°1300-5 - 20/03/2012 Montfort Mk2 EA Wood burning stove EN 13240 Model : 134 05 02 Technical manual Nominal output : 5 kW to be saved by the user for future reference THIS APPLIANCE CAN BE INSTALLED IN UK SMOKE CONTROL AREAS ONLY USING WOOD FUEL Parc d’activités de la Verte Rue...
-
Page 2: Table Of Contents
Montfort MK2 EA - 1340502 FRANCO BELGE congratulates you on your choice. FRANCO BELGE, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 80-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products. -
Page 3: Technical
Stove, in conformity with EN 13240 1.3. General characteristics • Intermittent-burning heating appliance. • Detachable flue spigot for rear or top chimney Reference ........134 05 02 connection. Nominal heat output ......kW • Front loading door fitted with large refractory glass Chimney draft required ...... -
Page 4: Installation Instructions
Montfort MK2 EA - 1340502 2. Installation instructions 2.1 Warning to the user Floor and walls Make sure that the floor can support the weight of the All the local and national regulations, and appliance, it's flue and any surround. The floor May in particular those relating to national and need to be re-inforced with e concrete screed to European standards, must be observed when... -
Page 5: Chimney Connector
Montfort MK2 EA - 1340502 If the appliance has to be located in an opening, this - The appliance must not support the weight of the distance must be extended to a minimum clearance flue. (A) of 550 mm from the pipe or the stove body to any - Consult a chimney specialist for advice on suitable combustible materials. -
Page 6: Pre-Utilisation Check
Montfort MK2 EA - 1340502 1 diameter lower than the flue spigot and be situated If the stove is regularly used, the chimney should as distant as possible from the flue connection of the be swept several times per year, together with the appliance. - Page 7 Montfort MK2 EA - 1340502 Figure 5a Figure 5b Figure 5c Figure 5d Figure 5 - Replacing the parts Technical manual "1300"...
-
Page 8: Instructions For User
Montfort MK2 EA - 1340502 3. Instructions for user required. The manufacturer will not be responsible for Do not attempt to relight the fire until the cause of the any damage caused to the appliance due to the fume emission has been identified and corrected. If incorrect use or installation of the appliance e.g. -
Page 9: Maintenance Of The Chimney
Montfort MK2 EA - 1340502 3.2. Instructions for use with wood - Open the primary air control (#C1). - Open the glass door and add fuel. Figure 6) - Leave the primary air control open for a few minutes to allow the initial volatiles in the fuel to burn. 3.2.1. - Page 10 Montfort MK2 EA - 1340502 • The external castings Can be cleaned using a soft lint- stove has cooled down. This is natural process which free cloth, which Can be used dry or slighty dampened. does not effect the quality of the enamel or the lifespan In case of any water splashes or condensation marks, on the appliance.
-
Page 11: Trouble Shooting
Montfort MK2 EA - 1340502 3.8. Trouble Shooting : This sign means that you should ask for a qualified engineer to do the work. Problem Probable causes - ACTION Fire difficult to start Wood green...or damp Use hard wood logs, which have been cut for at Fire goes out least two years and stored, under a ventilated shelter. -
Page 12: Spare Parts
A = 134 05 02 Y ; B = 134 05 02 L ; C = 134 05 02 B ; D = 134 05 02 E ; E = 134 05 02 P ;... - Page 13 Montfort MK2 EA - 1340502 Figure 8 - Stove - exploded view Notice de référence "1300"...
- Page 14 A = 134 05 02 Y ; B = 134 05 02 L ; C = 134 05 02 B ; D = 134 05 02 E ; E = 134 05 02 P ;...
- Page 15 Montfort MK2 EA - 1340502 Notes Technical manual "1300"...
- Page 16 Name and address of the installer : ............................................................Telephone : ................................Name and address of the customer : ............................................................Date of installation : .............................. 134 05 02 Model of the appliance : Y L B E ...
