SAVOIE GN
Gas stove,
EN 613
model 154 07 06
Natural gas (type G20, G25)
Category I 2E+ (FR) , I 2H (GB)
Description of the appliance
Installation instructions
Operating instructions
Spare parts
Warranty certificate
Document n°1184-1 ~ 26/07/2004
FR EN ES ES
Technical manual
to be saved
by the user
for future reference
STAUB FONDERIE
Head Office Address
2, rue Saint Gilles
68230 TURCKHEIM
RC Colmar
SIREN 439 330 325
Address - Administration and
manufacturing
BP 73
59660 MERVILLE (FRANCE)
Telephone : 00 333 28 43 43 43
Fax : 00 333 28 43 43 99
Subject to modifications.
PL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAVOIE GN 154 07 06 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FRANCO BELGE SAVOIE GN 154 07 06

Summary of Contents for FRANCO BELGE SAVOIE GN 154 07 06

  • Page 1 Document n°1184-1 ~ 26/07/2004 SAVOIE GN FR EN ES ES Gas stove, EN 613 model 154 07 06 Technical manual Natural gas (type G20, G25) Category I 2E+ (FR) , I 2H (GB) to be saved by the user for future reference Description of the appliance STAUB FONDERIE Installation instructions...

  • Page 2: Table Of Contents

    FRANCO BELGE, which has been granted the ISO 9001 certification, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 75-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products.

  • Page 3: Description Of The Unit

    Savoie GN - réf. 154 07 06 Description of the unit This appliance is a gas stove. WARNING This appliance must be installed in compliance with the rules in force by a competent engineer. The appliance must not be operated if the window is cracked or broken. The safety pilot on the burner must not be adjusted and must not be put out of operation.

  • Page 4: Operating Principle

    Savoie GN - réf. 154 07 06 Description of the unit access door, which are designed to stay cool, all other Operating principle parts are working surfaces and should not be touched. The glass and frame on this appliance acts as a The appliance is designed for operating only with the fireguard conforming to BS: 1945 –...

  • Page 5: Installation Instructions

    Savoie GN - réf. 154 07 06 Installation instructions 2. Installation instructions The appliance should only be installed by a D E P T H professional engineer, in the strict application of S H E L F normal practices and all safety precautions. The installation must be carried out according to the Standards and the Building Regulations.

  • Page 6: Smoke Exit

    Savoie GN - réf. 154 07 06 Installation instructions Chimney connector Smoke exit The premises should be in accordance with the building The flue collar is reversible so that the smoke exit can regulations. be done at rear (fig. 2) or on the top. •...

  • Page 7: Ceramic Fuelbed Layouts

    Please note that once the stove is lit, the coals become very hot, care must be taken when adjusting coals after the appliance has been lit. Franco Belge accept no responsibility for any injury sustained whilst handling hot ceramics.

  • Page 8: Commissinoing The Stove

    Savoie GN - réf. 154 07 06 Installation instructions Place the two remaining logs in the front of the firebed • Log Pattern Arrangement on top of the Embers. The “Y” shaped log should be Only the ceramics supplied with this appliance are to be placed first with one of the legs of the log sitting on top used.

  • Page 9: Instructions For User

    Savoie GN - réf. 154 07 06 Instructions for user 3. Instructions for user The appliance 154 07 06 is adjusted and sealed in • Running the appliance at low setting accordance with category (G20 ou G25). Ignite permanent pilot and run appliance at “High” A qualified installer must connect and commission setting for a minimum of 10 minutes as shown above.

  • Page 10: Maintenance

    Savoie GN - réf. 154 07 06 Instructions for user On propane, the cylinder could be empty. Safety devices The pilot is not burning or performing correctly? Burner safety : If there are faults in the gas supply or in Ensure the pilot flame is the correct size for the type of lighting, the safety device (thermocouple) will shut gas.

  • Page 11: Spare Parts

    Spare parts 4. Spare parts If any parts need to be replaced use only genuine Franco Belge parts, non-standard parts will invalidate the guarantee and may be dangerous. When ordering spare parts, specify the stove type and serial number, including the colour index (on the guarantee or identification plate), the name of the part and the part number.
  • Page 12 Savoie GN - réf. 154 07 06 Spare parts N° Codes Designation ....Type ..Qty 181617 Ceramic rope ......1,04 m 181625 Ceramic rope .

  • Page 13: Spare Parts

    Savoie GN - réf. 154 07 06 Spare parts Figure 4 - Spare parts view Notice de référence “1184”...
  • Page 14 § Guarantee certificate § This guarantee covers the replacement, in our § Legal guarantee factory, of parts recognised as being defective from The specifications, dimensions and information t h e o u t s e t b y o u r “ G u a r a n t e e I n s p e c t i o n ” shown on our documents are provided for information Department.
