Front-Panel
Buttons/LEDs
Reboot button
RST / UPG button
PWR
CFG
USB
MPEG-2
H.264
MP2
AAC
Dolby Digital
For
recording
IP
NACE:
610-429-1511
| sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0
Description
Reboots the device (unsaved settings will be lost)
To reset all the settings of the device to factory default:
1.Press and hold the RST/UPG button and then connect power to
the device while pressing in the RST/UPG button.
2.Hold the button until CFG led to flashes 10 times (about 10
seconds)
3.After the CFG led stops flashing -release the button
To upgrade firmware using the USB port:
1.Plug-in the USB drive with the upgraded firmware image
("hdip_upg.img")
2.Press and hold the RST/UPG button and boot-up the device
3.USB led will flash while copying the image from USB drive (about
3~5 seconds)
4.Wait until the CFG led stop flashing
5.Release the RST/CFG button and wait for the device to reboot
and upgrade the firmware (about 1 minutes)
Power is ON
Indicates device is in configuration mode
Indicates USB drive is mounted
Indicates device is encoding video using MPEG-2
Indicates device is encoding video using H.264
Indicates device is encoding audio using MPEG-1 Layer 2
Indicates device is encoding audio using AAC
Indicates device is encoding audio using Dolby Digital
Page 7
