System Installer must adhere to Article 820-40 of the NEC that provides guidelines for proper
grounding and specifies that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as possible.
Each unit is shipped factory tested. Ensure all items are removed from the container prior to discarding any packing
material.
Thoroughly inspect the unit for shipping damage with particular attention to connectors and controls. If there is any
sign of damage to the unit or damaged or loose connectors contact your distributor immediately. Do not put the
equipment into service if there is any indication of defect or damage.
It is highly recommended that quality cables and connectors be used for all video and audio source
connections
1. Connect the media source (Satellite STB, Media player, or other media device) to the HDIP streaming server
by HDMI, YPbPr, or CVBS cables.
2. Connect the HDIP streaming server to local area network (LAN).
3. Plug the power adapter to the device and power up
4. In the same network segment, find the HDIP streaming server from Windows XP/7 "My Network Places" **
Note: For Windows XP enable UpnP.
5. Open the device's GUI by double-clicking the device icon(XP)
There are three (3) use cases supported by HDIP streamer: DLNA media server, UDP/RTP multicasting, and
TCP/UDP/RTP unicasting.
1. All UPnP/DLNA devices, including the HDIP streaming server (media-server), media-players, the SmartTV, the
Limitations:
2. If a DHCP server is present in the private network, the DT-HDIPCOM will use the IP address assigned by the
set-top-box, and the controlling PC, should be located within same network segment/LAN.
3. If no DHCP server is present, the DT-HDIPCOM will use an assigned IP address (169.254.xxx.x).
DHCP server.
NACE:
610-429-1511
| sales@datatronix.biz | www.datatronix.biz | DT-HDIPCOM Manual v1.0
Installation
Unpacking and Inspection
Hardware Installation and Connections
Page 6
