INSTALLATION INSTRUCTIONS
MODEL WKP-8
WINDOWS KEYPANEL
™
9330-7548-000 Rev A, 10/96
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WKP-8 and is the answer not in the manual?

Questions and answers

Related Manuals for RTS WKP-8

Summary of Contents for RTS WKP-8

  • Page 1 INSTALLATION INSTRUCTIONS MODEL WKP-8 WINDOWS KEYPANEL ™ 9330-7548-000 Rev A, 10/96...

  • Page 2: General Description

    GENERAL DESCRIPTION The Windows Keypanel interfaces your IBM compatible PC to any Telex Digital Matrix Intercom System. The Win- dows Keypanel provides eight intercom talk/listen key pairs, plus call waiting, right on your computer monitor screen. Additional on-screen controls include a programming keypad, intercom volume control, and shortcut function keys for page, phone, point-to-point, IFB and party line assignment.
  • Page 3 Logical Keypanel Address Configuration switches 5-7 set the logical keypanel address for communication with the intercom system. Settings are summarized in Table 2. Note: DIP Switch 8 is not used. Determining the Logical Keypanel Address for CS9XXX Intercoms For intercom port numbers ending in 1 through 8, the address is the last digit of the port number. Port numbers ending in 0 or 9 cannot be used with the Windows Keypanel.

  • Page 4: Installing The Software

    DIP Switch Settings for Logical Keypanel Address Selection DIP SWITCH POSITIONS Remove you computer’s cover and locate an available 16-bit ISA expansion slot. Refer to your computer manual for details. Inside the computer, remove the expansion slot cover for the selected slot. Retain the cover mounting screw. It will be used to secure the Windows Keypanel Card.

  • Page 5: Connector Pin Assignments

    Checking the Installation Double-click on the Windows Keypanel icon to start the program. The Windows Keypanel should appear on the screen, and asterisks should briefly display above the talk keys. After a few moments, the key assignments should appear in the displays.
  • Page 6 Correspondence between Logical Keypanel Numbers and Port Numbers for ADAM and ADAM CS Intercom Systems Logical Keypanel Address 201 209 217 225 233 241 249 257 265 273 281 289 297 305 313 321 329 337 345 353 361 369 377 385 393 202 210 218 226 234 242 250 258 266 274 282 290 298 306 314 322 330 338 346 354 362 370 378 386 394 203 211 219 227 235 243 251 259 267 275 283 291 299 307 315 323 331 339 347 355 363 371 379 387 395 204 212 220 228 236 244 252 260 268 276 284 292 300 308 316 324 332 340 348 356 364 372 380 388 396...
