USB-EXT-2-LOCAL-1G/USB-EXT-2-REMOTE-1G

Verify the Installation

Check that the ACT, HOST, LINK, and PWR LEDs light on both the
USB-EXT-2-LOCAL-1G and the USB-EXT-2-REMOTE-1G. If the HOST or
LINK LEDs do not light, then the cabling between the USB extenders may
be installed incorrectly or may be defective.
The following table describes the behavior of the LEDs on the front panel
of the USB extender.
LED Color
ACT
Flashing Data transmission is occurring between the
amber USB-EXT-2-LOCAL-1G and the
USB-EXT-2-REMOTE-1G.
HOST
Solid green The host device is recognizing the USB extender.
LINK A valid link is established between the USB
Solid green
extender.
Fast-flashing The USB extender is in Pairing mode.
green
Slow-flashing The USB extender is attempting to establish a
green link.
PWR
Blue The USB extender is receiving power.
Description
Additionally, check to see whether USB extender system has been installed
correctly on the host computer. Refer to the below instructions.
For Windows Software:
1. Open Device Manager.
2. Expand the Universal Serial Bus controllers node.
3. Check to see if the extender system appears on the list of controllers.
If the extender system has been properly installed, it appears on the
list as a "Generic USB Hub."
For macOS Software:
1. Open System Profiler.
2. In the left column under Hardware, select USB.
3. Check to see if the extender system appears in the USB Device Tree at
the top right of the System Profiler window. If the extender system
has been properly installed, it is listed as a "Hub" under the USB High-
Speed Bus/USB Bus node.
If the USB extender system does not detect correctly or fails to detect,
refer to "Troubleshoot the USB
Quick Start
Extender."
5
