USB-EXT-2-LOCAL-1G/USB-EXT-2-REMOTE-1G
2. Connect one RJ45 connector end of the CAT5e (or better) cable to the
LINK port on the USB-EXT-2-LOCAL-1G, and then connect the other
RJ45 connector end to the LINK port on the USB-EXT-2-REMOTE-1G.
The maximum cable distance is 330 ft (100 m).
CAUTION: The USB-EXT-2-LOCAL-1G and
USB-EXT-2-REMOTE-1G are intended for use as point-to-point
USB extenders. and must not be connected an Ethernet LAN or any
other network device via the LINK port.
Do not connect the USB-EXT-2-LOCAL-1G and
USB-EXT-2-REMOTE-1G to a USB-NX2-LOCAL-1G and
USB-NX2-REMOTE-1G.
NOTE: The CAT5e (or better) shielded twisted-pair (STP) cable
must have a straight-through conductor configuration with no
crossovers and must be terminated with 8-conductor RJ45
connectors at both ends.
3. Using a USB 2.0 A to B cable (not included), connect the USB B end into
the USB-EXT-2-LOCAL-1G host port (
A end of the cable into a USB type A port on the host device (USB 1.1 or
2.0 compatible).
), and then connect the USB
