- Diagnosis assistance

Diagnosis assistance

1 - Recommendations

If a malfunction occurs, check the following points :
• Sufficient hydraulic oil in the tank.
• Batteries are charging.
• Control box E-stop push-buttons are pulled out.
• The control box selector key is set to platform or ground control box.
• Control box relays are engaged.
• Fuse status.
• Ground control box solenoid valve status.
If the malfunction persists, consult the troubleshooting table to identify the problem.
IF you cannot identify the problem, contact HAULOTTE Services®.

2 - Troubleshooting

Problem
Ground control box selector key is set to
ground control box position
Platform overload indicator
'Enable Switch' control validation device is
not enabled
or
Enabled for more than 7 s without movement
No driving
Faulty joystick
Control box power cable is damaged
Tilt or slope exceeding the authorised limit
Outside temperature range ( 0°/40°C)
Faulty speed variator
Reducing grear not released
No power in horizontal
drive mode
Speed selector switch in the wrong position Select the high speed ( GV) mode
Platform extended
Faulty speed variator
No high speed
Speed selector switch in the wrong position Select the high speed ( GV) mode
Faulty batteries
Faulty speed variator
No low speed Speed selector switch in the wrong position Select the high speed ( PV) mode
Faulty batteries
4000358110
Diagnosis HA12IP - HA33JE - HA15IP - HA43JE
Probable cause
E10.16
Solution
Turn the ground control box selector key to platform control
box position
Remove some weight
Do not exceed the authorised limit
characteristics
Enable the device and keep pressed down during movement
Replace the joystick
Contact HAULOTTE Services®
Repair or replace the cable
Lower the arm and boom
Do not exceed the authorised limit
characteristics
The audible beep sounds : Lower the arm and boom
Check the diagnosis LED
Check the release solenoid valve
Retract the arm, boom and pendular arm below the
horizontal axis
Check the connections
Replace the batteries
Check the connections
Replace the batteries
