Physio Control LIFEPAK 15 V2 Manual page 5

Doc
3339111 Rev:
ID:
1 st
Work 1
Verify
Remove Screws
(4 places)
Template: 7000743_B
A Title: LP15 V2 System Board Reprogramming Process
2 2 nd Verify
Remove Screws
(4 places)
!
Tool Caution
1. Initial Power Check
Install a fully charged battery onto the LIFEPAK 15
monitor/defibrillator. Press the ON key. If the screen flashes
white and then becomes blank, the unit is bricked.
2. Disassembling the Case
2.1
2.2
2.3
2.4
2.5
N
Shock
Orient
W E
Hazard
S
Remove all cables and patient connections, and then
remove the batteries.
If applicable, remove the carrying case.
Remove the four front mounting screws (REF 21300-
007253) from the bumpers (Torx-15).
Remove the four rear mounting screws (REF 21300-
007253) from the bumpers (Torx-15).
Remove the bumpers (REF 21300-007356 and
21300-007010) from the case and set aside.
5 of 31
