Doc
3339111 Rev:
ID:
1 st
Work 1
Verify
Tools Required: (substitution of equivalent or better equipment allowed)
Computer – Win 7 or 10 software
Fixture, LP15 System Board FPGA Programming (3339034)
Firmware- FPGA, Programmed, LP15 System Board (3207723)
LIFEPAK 15 To PC Interconnect Cable 11230-000005, 11230-000020, or 11996-000369.
Torque Driver – Hand Operation, with an adjustable range of 5 – 12 in-lbs.
Driver Bits – P1 (2"minimum shaft), P2 (5" minimum shaft), Torx, T-15 (2" minimum shaft).
3/8'' nutdriver
Static-dissipative mat and wrist strap
Fixture Assembly, Capacitor Discharger 3012102 or 2673832.
Tools defined in the LP15 Service Manual, 3300117, Replacement Procedures Tool list
See Tools defined in the PIP - TCP sections of LIFEPAK 15 PIP Test Procedure, 3207841 or in Test Procedure, CAPIP, 3301593
for additional test tools required for performance testing
All tools requiring calibration should be calibrated and within their calibration cycle dates.
Torque Driver conversions – 4 in-lbs. = 45 cNm, 6.8 in-lbs. = 77 cNm, 10 in-lbs. = 113 cNm
•
Documentation Required:
LP15 V2 System Board FPGA Debrick Programming Procedure
Instructions for use, Combined Service Configurator Loader
LIFEPAK 15 PIP/TCP Manual Procedure
LIFEPAK 15 V1/V2 Service Manual, CD
Work Instructions – CAPIP Test (where applicable)
Device Compliance Tool (where available)
Instructions, Setup Mode, LP15, V2, V4
Template: 7000743_B
A Title: LP15 V2 System Board Reprogramming Process
2 2 nd Verify Tool
Shock
!
Caution
Hazard
3339230
3206073
3207841
3309059 (V1/V2)
3301593
3316610
3306226
N
Orient Clean
W E
S
3 of 31
