Doc
3339111 Rev:
ID:
1 st
Work 1
Verify
Purpose:
This instruction guides the Service Depot and Aftermarket Operations operator through the process to allow direct programming of
the FPGA firmware to the system board 3206834 via direct connection in order to recover a bricked system board in a LIFEPAK
15 version 2 monitor/defibrillator.
Scope:
This document is limited to LIFEPAK 15 V2 monitor/defibrillators, 3306272-All (Version 2), that are "bricked"
These instructions are intended for authorized Service Depot and Aftermarket Operations Technicians who have reviewed the
procedure and who are familiar with the LIFEPAK 15 V2 device and will only be performed in a regional Service Depots. The
LIFEPAK 15 V1/V2 Service Manual and the applicable Performance Inspection Procedure will be used in conjunction with this
Service Process Work Instruction.
Definitions:
Table 1: Definitions, Acronyms, and Abbreviations
Term /
Abbreviation
"Bricked"
PIP-TCP
FPGA
Training:
As a prerequisite, only personnel that have completed training on this LP15 V2 System Board Reprogramming process are
permitted to perform this process on the LIFEPAK 15 V2 device. An individual will be considered fully trained when they meet the
requirements as defined in the Training Work Instruction, 7000045 on the following documents:
LP15 V2 System Board Reprogramming Process, 3339111
•
LP15 V2 System Board FPGA Debrick Programming Procedure, 3339230
•
Test Procedure, CAPIP, 3301593 Or Test Procedure, Manual PIP-TCP, LP15,3207841
•
Template: 7000743_B
A Title: LP15 V2 System Board Reprogramming Process
2 2 nd Verify Tool
Software has not been loaded correctly into the FPGA.
Performance Inspection Procedure – Test and Calibration Procedure. The procedures
used to test a device to ensure that it is within defined specifications.
Field Programmable Gate Array
Shock
!
Caution
Hazard
Definition
N
Orient Clean
W E
S
®
2 of 31
