Installation Instructions
PowerFlex 700H and 700S AC Drives Frame 9 Main Fan
Capacitor Replacement Kit
PFLEX-IN024B-EN-P
ATTENTION: This drive contains ESD (Electrostatic Discharge) sensitive
parts and assemblies. Static control precautions are required when
installing, testing, servicing or repairing this assembly. Component
damage may result if ESD control procedures are not followed. If you are
not familiar with static control procedures, reference A-B publication
8000-4.5.2, "Guarding Against Electrostatic Damage" or any other
applicable ESD protection guide.
ATTENTION: Only qualified personnel familiar with adjustable frequency
AC drives and associated machinery should perform maintenance/repair of
the system. Failure to comply may result in personal injury and/or
equipment damage.
ATTENTION: The following information is merely a guide for proper
installation. Rockwell Automation cannot assume responsibility for the
compliance or the noncompliance to any code, national, local or otherwise
for the proper installation of this drive or associated equipment. A hazard
of personal injury and/or equipment damage exists if codes are ignored
during installation.
Advertisement
Related Manuals for Rockwell Automation Allen-Bradley PowerFlex 700H
Summary of Contents for Rockwell Automation Allen-Bradley PowerFlex 700H
- Page 1 ATTENTION: The following information is merely a guide for proper installation. Rockwell Automation cannot assume responsibility for the compliance or the noncompliance to any code, national, local or otherwise for the proper installation of this drive or associated equipment. A hazard of personal injury and/or equipment damage exists if codes are ignored during installation.
-
Page 2: What You Need To Do
• Step 1: Remove power from the drive What You Need to Do • Step 2: Remove the lower protective cover • Step 3: Remove the existing fan capacitor • Step 4: Install the new fan capacitor and bracket Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011... -
Page 3: Step: 1 Remove Power From The Drive
Step: 2 Remove the Lower cover to the drive and remove the cover. Tightening torque for re-assembly Protective Cover is 3 N m (27 lb in.). • • U/T1 V/T2 W/T3 U/T1 V/T2 W/T3 Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011... - Page 4 2. Remove the M4 x 8 mm POZIDRIV screw that secures the fan inverter cover to the drive frame and remove the cover. Discard the existing fan inverter cover and screw -- new parts are provided in the kit. Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011...
- Page 5 Note that the fan capacitor is still connected to the drive circuitry. Discard the two M5 x 10 mm screws -- new hardware is provided in the kit. 7. Disconnect the capacitor wires from the connectors labelled “Blue” and “Brown”. Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011...
- Page 6 PowerFlex 700H and 700S AC Drives Frame 9 Main Fan Capacitor Replacement Kit Remove screws and bracket Disconnect fan capacitor wires from connectors labelled “Blue” and “Brown” Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011...
- Page 7 Discard the two M4 x 8 mm screws -- new hardware is provided in the kit. 10. Discard the existing fan capacitor and bracket. Remove screws and fuse holder Remove screws and stirring fan. Note direction of air flow arrow. Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011...
- Page 8 4. Install the existing fuses in the fuse holder. 5. Connect the blue fan capacitor wire to the connector labelled “Blue” and the brown fan capacitor wire to the connector labelled “Brown”. Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011...
- Page 9 10. Secure the new fan inverter cover to the drive chassis using the new M4 x 8 mm POIDRIV screw provided in the kit. Tightening torque is 2 N • (17 lb in.). • Rockwell Automation Publication PFLEX-IN024B-EN-P - September 2011...
