Installation Guide
UT56TBC3M
UT56WW3M
UT56xx3M
E144735
net fan weight: 13.5 lbs. (6.1 KG)

Table of Contents:

Wiring. pg. 5
Test Fan. pg. 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UT56 3M Series and is the answer not in the manual?

Questions and answers

Related Manuals for Litex UT56 3M Series

Summary of Contents for Litex UT56 3M Series

  • Page 1: Table Of Contents

    Installation Guide UT56TBC3M UT56WW3M UT56xx3M Table of Contents: Safety Tips. pg. 1 Unpacking your fan. pg. 2 Installation preparation. pg. 3 Fan Assembly. pg. 4 Wiring. pg. 5 Canopy Assembly. pg. 6 Light Kit Assembly. pg. 7 Test Fan. pg. 7 Troubleshooting.

  • Page 2: Safety Tips

    SAFETY TIPS WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. Read all instructions and safety information carefully before installing your fan and save these instructions.

  • Page 3: Unpacking Your Fan

    1. Unpacking your fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation blade edge To prevent personal injury and damage ensure that the hanging location allows the blades a clearance of 84" from the floor and 30" from any inches wall or obstruction. inches This fan is suitable for room sizes up to 400 square feet.

  • Page 5: Fan Assembly

    5. Fan Assembly. Loosen canopy set screw and lower canopy to expose hanging bar. Separate electrical wiring and safety cable from rubber band. Lift fan onto j-hook hanging bracket and slide rubber bushing over hook. Make the wiring connections as j-hook shown in steps 6.

  • Page 6: Wiring

    wall control wire 6. Wiring. from wood joist ceiling safety cable black Find a secure attachment point(wood ceiling white joist) and secure safety cable. Use a heavy duty wood screw wood screw(not supplied), washer and lock & washer washer (not supplied) over safety cable loop. Important: Be sure outlet box is properly grounded or that a ground (GREEN or Bare) wire is present.

  • Page 7: Canopy Assembly

    8. Canopy Assembly. Lift canopy over hanging bracket and tighten the canopy set screw to secure canopy. canopy canopy set screw 9. Blade Assembly. Remove screw and washer from top of motor housing and leave lower washer and rubber cushion intact. Lower blade over rubber cushion and attach with previously removed screw and washer.

  • Page 8: Light Kit Assembly

    Service at 1-800-527-1292 to arrange for return of fan. any issues before contacting customer service. Return fan, shipping prepaid to Litex Industries, Inc. We will repair or ship you a replacement fan, and we will pay the return shipping cost.
