Board Jumper Setting Drawing
Mainboard Jumpers and Connectors Location
Backplane Jumpers and Connectors Location
6 ITA-2111 Startup Manual
PWR1
USB1_2
PC104_ISA
PC104_PCI
VIO1
COM5_8
USB3
PCI_PCIE_USB1
LAN1_2
CAN1_2
