Video intercoms for the IP360 system
FB01187-EN
XTS 5IP WH - XTS 5IP BK
INSTALLATION AND SETTINGS MANUAL
EN English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XTS 5IP WH and is the answer not in the manual?

Questions and answers

Related Manuals for CAME BPT XTS 5IP WH

Summary of Contents for CAME BPT XTS 5IP WH

  • Page 1 Video intercoms for the IP360 system FB01187-EN XTS 5IP WH - XTS 5IP BK INSTALLATION AND SETTINGS MANUAL EN English...

  • Page 2: General Precautions

    General Precautions Read the instructions carefully before beginning the installation and carry out the actions as specified by the • manufacturer. The installation, programming, commissioning and maintenance of the product must only be carried out by • qualified technicians, properly trained in compliance with the regulations in force, including health and safety measures and the disposal of packaging.

  • Page 3: Function Of Terminals

    F Reset button. When pressed it reboots the device; this operation DOES NOT require any deleting of program- ming. Function of terminals Local power supply input Landing call input Alarm input Technical data Type XTS 5IP local power supply (V DC) 14 to 18 PoE power supply IEEE 802.3af-PD...
  • Page 4 INSTALLING...
  • Page 5 To make the device's installation more solid, use the supplied screws and dowels to fasten the frame to the wall.

  • Page 6: Examples Of Installation

    Examples of installation Single-household system with PoE power-supply Switch PoE Modem router Wi-Fi MTMV/IP Single-household system with onsite power supply units VAS/101 Modem router Wi-Fi MTMV/IP VAS/101...
  • Page 7 Multi-household system with indoor receivers in each apartment; one of these indoor receivers can be managed over smartphones and Tablet PCs APARTMENT 4 APARTMENT 4 APARTMENT 3 VAS/100.30 MODEM ETI/MiniSER ROUTER Wi-Fi SWITCH PoE APARTMENT 2 APARTMENT 1 SWITCH PoE Master Slave MTMV/IP...

  • Page 8: Advanced Settings

    COMMISSIONING Once the wiring is complete, the functions essential for the device to work properly need to be programmed. Scroll the available pages. Select item A. Settings 21:20 Thursday 15 Mar 2018 Info Back Home Scroll the list. Select menu item B. Auxiliary setting Backdrops Display...
  • Page 9 Network This section is for configuring the network connection. Type of connection Mode DHCP Static IP address Netmask Gateway MAC address Save 21:20 Thursday 15 Mar 2018 Info Back Home A Lets you choose the type of address from: DHCP The device's IP address is assigned by the DHCP server;...

  • Page 10: Sip Settings

    SIP Settings Manual Mode A In this space enter the “SIP Us- Mode Manual Automatic ername” assigned to the device by Flat ID PCS Xip. B In this space type any password Username assigned in the receiver's creden- Password tials in the server's setup window. Display name C Name assigned to the device.

  • Page 11: Automatic Door Opener

    Automatic door opener This function, which is especially useful for businesses, lets you automatically open the entrance once the call-but- ton is pressed on the entry panel. The activation of this function can be programmed to schedule time slots and days of the week.

  • Page 12: Configuring The User Interface

    For editing the selected ele- ment. 08:30 - 12:30 For eliminating the selected Mon Tue Wed Thu Fri element. 13:30 - 18:30 Mon Tue Wed Thu Fri Touch the button Back to return to time-slot the list of configurable parameters. Delete all 21:20 Thursday...

  • Page 13: Maintenance

    Touch each of the empty sections and use the drop-down menu to select the content that you want to Number of frames assign to the section. Empty Empty Save the setting by touching the Save button. Empty Settings Save 21:20 Thursday 15 Mar 2018 Info...
  • Page 14 SETTINGS ONLY AVAILABLE ON WEBPAGE The webpages, besides allowing you to set most of the parameters that may be set up on the indoor receiver's interface, also allow you to run certain additional functions shown in this section. In the Chrome, Firefox, Safari browsers' address bar, type the de- XTS 5 IP vices address..

  • Page 15: Change Password

    Change password Maintenance Help Exit In this window you can change the password used for accessing. System UPDATE... CHANGE PASSW... CONFIGUR... Date and Time PASSWORD Network NEW PASSWORD IP video cameras Voicemail CONFIRM NEW PASSWORD Maintenance Diagnostics Save Cancel Diagnostics Diagnostics Help Exit...
  • Page 16 Pertinent Regulations. This product complies with the law. Decommissioning and disposal. Dispose of the packaging and the device at the end of its life cycle responsibly, in compliance with the laws in force in the country where the product is used. The recyclable components are marked with a symbol and the material's ID marker.

This manual is also suitable for:

Xts 5ip bk
