5.7 Description of the front panel

On the front panel is the following:
Caption Connector
PWR 2-pin
ETH0 RJ45
ETH1 RJ45
ANT SMA
DIV SMA
WIFI R-SMA
SIM1 —
SIM2 —
Description
Connector for the power supply.
Connector for connection into the local computer network.
Connector for connection into the local computer network.
Connector for main antenna.
Connector for diversity antenna.
Connector for WIFI antenna. Available only when the
router is equipped with WIFI module.
Holder for the first SIM card.
Holder for the second SIM card.
Table 8: Front panel description
Figure 17: Front panel UR5i v2 Libratum
13
UR5i v2 Libratum
