Hardware Manual
Industrial Cellular Router
ICR-2734
Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Document No. MAN-0066-EN, revision from 15th November, 2023.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICR-2734 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech ICR-2734

Summary of Contents for Advantech ICR-2734

  • Page 1 Hardware Manual Industrial Cellular Router ICR-2734 Advantech Czech s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic Document No. MAN-0066-EN, revision from 15th November, 2023.
  • Page 2 © 2023 Advantech Czech s.r.o. No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photography, recording, or any information storage and retrieval system without written consent. Information in this manual is subject to change without notice, and it does not represent a commitment on the part of Advantech.
  • Page 3 Used symbols Danger – Information regarding user safety or potential damage to the router. Attention – Problems that can arise in specific situations. Information – Useful tips or information of special interest.

  • Page 4: Table Of Contents

    Contents 1. Product Overview 1.1 Product Introduction ......... 1.2 Product Usage Examples .
  • Page 5 List of Figures Access to the Internet from LAN ........Backed up Access to the Internet .
  • Page 6 List of Tables Hardware Overview of the Router ........Order Codes Overview .

  • Page 7: Product Overview

    1. Product Overview 1.1 Product Introduction Industrial cellular router ICR-2734 is designed for wireless communication in mobile networks that use traditional cellular technologies. The primary purpose of this router is its use in the Category 4 (Cat.4) services on the cellular LTE network.

  • Page 8: Product Usage Examples

    • This example illustrates a typical case when the cellular router is used to access the Internet through the cellular network. • Not supported by LAN routers without a cellular interface. Figure 1: Access to the Internet from LAN ICR-2734 Hardware Manual (preliminary version)

  • Page 9: Backed Up Access To The Internet

    • This example illustrates the function of backing up the access to the Internet for a cellular router. • The access can be backed up by a PPPoE connection, Ethernet wired connection, or by WiFi (for models supporting WiFi). Figure 2: Backed up Access to the Internet ICR-2734 Hardware Manual (preliminary version)

  • Page 10: Using Vpn Tunnel

    1.2 Product Usage Examples Secure networks interconnection or using VPN • This example illustrates the secure VPN tunnel interconnection between the configured Advantech router and a router of a remote network behind the Internet. The cellular network is used to connect the configured router to the Internet.

  • Page 11: Hardware Overview

    USB-A type socket connector; see Chapter 2.6. ETH0, ETH1 RJ45 100 MB Ethernet connection for the firts and second LAN; see Chapter 2.3. 2-pin Power supply socket; see Chapter 2.4. terminal Continued on the next page ICR-2734 Hardware Manual (preliminary version)

  • Page 12: Hardware Overview Of The Router

    DIN clip DIN rail clip, included as standard accessories; see Chap- ter 1.9. Grounding Pay attention to proper grounding of model with metal box; screw see Chapter 2.4. Table 1: Hardware Overview of the Router ICR-2734 Hardware Manual (preliminary version)

  • Page 13: Order Codes

    LTE Cat.4 with 3G/2G fallback module, ETH0, ETH1, USB, two SIM readers, dual-band WiFi, accessories with Ethernet cable, two cellular with one WiFi antennas, and UK power supply Table 2: Order Codes Overview ICR-2734 Hardware Manual (preliminary version)

  • Page 14: Product Revisions

    Description Initial version (revision number not printed on the labels). WiFi support added to the mainboard; see PCN-2023-10 for details. Changed color of the DAT LED; see PCN-2023-11 for details. Table 3: HW Revisions History ICR-2734 Hardware Manual (preliminary version)

  • Page 15: Package Contents And Accessories

    Ethernet cross cable of length 1.5 m. 0 / 1 pc Order code: BB-KD-ETH 5G/LTE Antenna (SMA male). 0 / 2 pcs Order code: ANT-LTE5G-025 WiFi Antenna (RP-SMA male). 0 / 1 pc Order code: BB-AW-A2458G-FSRPK Continued on the next page ICR-2734 Hardware Manual (preliminary version)
  • Page 16 Wall mount power supply, 12V/1A with UK plug. 0 / 1 pc Order code: BB-RPS-v2-UK Wall mount power supply, 12V/1A with US plug. 0 / 1 pc Order code: BB-RPS-v2-US Table 4: Contents of Package ICR-2734 Hardware Manual (preliminary version)

  • Page 17: Product Dimensions

    For the dimensions of the product in metal and plastic boxes see the figures below. Note that all sizes are measured in millimeters. Variant with Metal Box Figure 5: Metal Box – Top, Side and Front View ICR-2734 Hardware Manual (preliminary version)
  • Page 18 1. Product Overview 1.7 Product Dimensions Variant with Plastic Box Figure 6: Plastic Box – Top, Side and Front View ICR-2734 Hardware Manual (preliminary version)

  • Page 19: Mounting Recommendations

    • Sufficient space must be left between each connector for the handling of cables, • To ensure the correct functioning of the router we recommend the use of an earth-bonding distribution frame for the grounding of the grounding screew, see Chapter 2.4. ICR-2734 Hardware Manual (preliminary version)

  • Page 20: Din Rail Mounting

    DIN rail clip hitched to the DIN rail get out of this rail and then fold out the bottom part of the router away from the DIN rail, see Figure 8. Figure 8: Removing Router from the DIN Rail ICR-2734 Hardware Manual (preliminary version)

  • Page 21: Product Label

    1. Product Overview 1.10 Product Label 1.10 Product Label The figure below shows an example of the product labels with all the information printed on them. Figure 9: Product Label ICR-2734 Hardware Manual (preliminary version)

  • Page 22: Hardware Functionality

    • To insert a SIM card, push the card into the slot until it clicks into place. • Swipe down the cover and tighten the cover screws. Figure 10: SIM Cards Insertion ICR-2734 Hardware Manual (preliminary version)

  • Page 23: Antennas

    Receive Data+ (positive pole) — — — — Receive Data- (negative pole) — — — — Table 5: Ethernet Connector Pinout Description The isolation barrier of the Ethernet ports against the ground is 1500 V. ICR-2734 Hardware Manual (preliminary version)

  • Page 24: Power Supply

    All metal parts of the router in a metal box, including the box itself, are connected with the negative pole of the power supply (common pole). If recommended for the installation environment, protect the router by grounding it properly by the grounding screw, see Figure 13. Figure 13: Position of the Grounding Screw ICR-2734 Hardware Manual (preliminary version)

  • Page 25: Low Power Mode

    • To mount the drive to the mnt directory, use the mount command: mount /dev/sda1 /mnt For more information about the commands for creating, mounting, checking, and unmounting a file system on a USB Flash Drive, consult the application note for the Ext4_tools router app. ICR-2734 Hardware Manual (preliminary version)

  • Page 26: Usb Connector Pinout

    Positive pole of 5 V DC supply voltage, 0.5 A USB data - USB data signal – negative pole Input/Output USB data + USB data signal – positive pole Input/Output Negative pole of DC supply voltage Table 7: USB Connector Pinout ICR-2734 Hardware Manual (preliminary version)

  • Page 27: Led Status Indication

    Selected 100 Mbps bit rate. ETH1 Green Selected 10 Mbps bit rate. ETH0 Orange The network cable is connected. ETH1 Orange Brief off blinks Data transmission. Orange The network cable is not connected. Table 8: LED Status Indication ICR-2734 Hardware Manual (preliminary version)

  • Page 28: Reset Functions

    RST button for at least 10 seconds. This action will reset the router’s configuration to the default settings. Use a narrow screwdriver or any small tool to press the RST button. Figure 15: Resetting the Router ICR-2734 Hardware Manual (preliminary version)

  • Page 29: First Use

    WebAccess/DMP server. See the configuration manual [1], chapter Basic Information -> WebAccess/DMP Configuration, for more information. If the router’s label lacks a unique password, use the password root . ICR-2734 Hardware Manual (preliminary version)

  • Page 30: Technical Specifications

    SMA female connectors for LTE – 50 WiFi RP-SMA female connector for WiFi – 50 Interfaces ETH0 RJ-45 socket for 10/100 Mbps Ethernet ETH1 RJ-45 socket for 10/100 Mbps Ethernet USB-A socket Table 9: Basic Parameters ICR-2734 Hardware Manual (preliminary version)

  • Page 31: Standards And Regulations

    EN 61000-4-11, EN 61000-6-2, EN 61000-6-3, EN 55032 Safety IEC 62368-1, IEEE 802.3 Transportation E-Mark (E8), homologation number: 10R-06 13493 National CE, UKCA compliant Environmental REACH, RoHS3 and WEEE compliant Table 10: Standards and Regulations ICR-2734 Hardware Manual (preliminary version)

  • Page 32: Type Tests And Environmental Conditions

    Radiated emission EN 55032 Enclosure Cl. B,30MHz-1GHz,1GHz-6GHz Class B, 150 kHz – 30 MHz Class B, 150 kHz – 30 MHz AC/DC Class B, 150 kHz – 30 MHz Table 11: Type Tests and Environmental Conditions ICR-2734 Hardware Manual (preliminary version)

  • Page 33: Parameters Of Cellular Module

    Bit rates: max. 21 Mbps (DL) / 5.7 Mbps (UL) EDGE/GPRS Supported frequencies: B5 (850 MHz), B8 (900 MHz) parameters B3 (1800 MHz), B2 (1900 MHz) Bit rates: max. 237 kbps (DL) / 237 kbps (UL) Table 12: Technical Parameters of Cellular Module ICR-2734 Hardware Manual (preliminary version)

  • Page 34: Parameters Of Wifi

    Multirole (STA&AP) Security – Standards WPA, WPA2, WPA3, 802.1X Security – Encryption WEP, TKIP, AES TX Power Max. 18 dBm @ 2.4 GHz Max. 15 dBm @ 5 GHz Table 13: Technical Parameters of WiFi ICR-2734 Hardware Manual (preliminary version)

  • Page 35: System Configuration

    • 512 MB for customer data RAM size 128 MB Watchdog HW Watchdog Battery Backup RTC Trusted Platform Module (TPM) 2.0 Table 14: System Configuration Not assembled by default, for a dedicated customer order only. ICR-2734 Hardware Manual (preliminary version)

  • Page 36: Appendix A: Troubleshooting

    Also enable "Send all remaining incoming packets to default server" feature and fill in the IP address of your Web server. On the Web server, the default gateway has to be the IP address of the router. DynDNS doesn’t work. • With private APN this will not work. ICR-2734 Hardware Manual (preliminary version)
  • Page 37 I switched the router to offline mode by SMS message, but the router is in online mode after reboot. • SMS messages do not change the router configuration. They remain in effect only until the router is rebooted. ICR-2734 Hardware Manual (preliminary version)
  • Page 38 Web interface in "Configuration" section, "Services", "SSH". Then connect with any SSH client on port 22 of the router. User and password is the same as for the Web interface. Telnet on v2 routers can be enabled here: "Configuration" section, "Services", "Telnet". ICR-2734 Hardware Manual (preliminary version)
  • Page 39 +1-800-346-3119 (Monday – Friday, 7 a.m. to 5:30 p.m. CST) Fax: +1-815-433-5109 E-mail: support@advantech-bb.com Web: www.advantech-bb.com Customer Support for Asia Phone: +886-2-2792-7818 #1299 (Monday – Friday, 9 a.m. to 5:30 p.m. UTC+8) Fax: +886-2-2794-7327 E-mail: icg.support@advantech.com.tw Web: www.advantech.com ICR-2734 Hardware Manual (preliminary version)
  • Page 40 Remove the battery from the device before disposal. The battery in the device needs to be disposed of apart accordingly. Check the terms and conditions of your supplier for disposal information. ICR-2734 Hardware Manual (preliminary version)
  • Page 41 Appendix D: Related Documents ICR-2[78]00 Configuration Manual [EP] Product-related documents and applications can be obtained on Engineering Portal at https://icr.advantech.com/download address. ICR-2734 Hardware Manual (preliminary version)
  • Page 42 We, Advantech Czech s.r.o., declare that the radio equipment narrated in this user’s manual complies with Directive 2014/53/EU. We, Advantech Czech s.r.o., declare that the radio equipment narrated in this user’s manual complies with Radio Equipment Regulations 2017 (S.I. 2017 No. 1206).
