Standards and regulations
Safety
E-Mark – EMC for de-
vices in transportation
RCM – EMC and RF
according to Australi-
an standards

7.3 Technical parameters of module

HSPA+ module
HSPA+ parameters
UMTS parameters
GPRS/EDGE
parameters
Support channels
Depending on the capabilities of the operator.
Continued from previous page
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
+ AC:2011, EN 62311:2008
E-Mark homologation number: 10R – 04 7055
AS/NZS CISPR 32: 2015,
CISPR 32: 2015,
AS/NZS 4268: 2012 Amdt 1-2013
Table 15: Standards and regulations
Bit rate 14,4 Mbps (DL) / 5,76 Mbps (UL)
3GPP rel. 6/7 standard
Data compress 3GPP
Bit rate 384 kbps (DL) / 384 kbps (UL)
3GPP rel. 4 standard
EDGE bit rate 237 kbps (DL) / 237 kbps (UL)
GPRS bit rate 85,6 kbps (DL) / 85,6 kbps (UL)
Multislot class 12, CS 1 to 4,
3GPP rel. 99/4 standard
UMTS/HSDPA/HSUPA/HSPA+: B6 (800 MHz), B5 (850 MHz),
B8 (900 MHz), B2 (1900 MHz), B1 (2100 MHz)
GSM/GPRS/EDGE: 850/900/1800/1900 MHz
Max power – typical 26–33 dBm
Table 16: Technical parameters of module
