GCX 7000-MS3 Installation Manual

3875 Cypress Drive Petaluma, CA 94954 800.228.2555 707.773.1100 Fax 707.773.1180
Roll Stand Post Mount for 75mm VESA Data Capture Devices on Welch Allyn
Purpose: To describe installation of Post Mounting Assembly to Welch Allyn Roll Stand
The purpose of this manual is to describe general installation of Post Mounting Assembly to Welch Allyn
Roll Stand. This manual should be used in conjunction with any instrument-specific installation guides.
Please read this manual and all instrument-specific installation material before installing or using this
product.
Ensure that the weight of the instrument being mounted does not exceed the load
rating limit of 10lb. Failure to do so may result in damage to equipment or injury.

Parts Reference

The following parts and hardware are included in this installation kit:
(
Hardware not shown)
Item # Description
1 Post Mounting Assembly
Clamping Block
2
3 Cable Clip
4 10-32 X 5/8 Socket Head Cap Screw
5 M4 X 8mm Pan Head Machine Screws
Tools Required:

3/16" Hex Wrench (Provided)

5/32 Hex Wrench (Provided)

Phillips Screwdriver (Not Provided)

2X 1/2"/13mm Wrench (Not Provided)
7000-MS3 Roll Stand
(Refer to qualified personnel)
www.gcx.com
Installation Guide
Qty.
1
1
3
2
4
DU-CAP-0002-67 Rev A 2/16/16 GCX Corp Page 1 of 3
1
2
3
