DEMO MANUAL DC1825A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 1 C3
3 1 C4
4 1 D1
5 1 D2
6 1 R1
7 1 R2
8 1 R3
9 1 T1
10 1 U1
Additional Demo Board Circuit Components
1 0 C1
2 0 R4
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP., X7R, 2.2µF 100V, 10% 1210
CAP., X5R, 100µF 6.3V, 20% 1210
CAP., X7R, 4700pF 1000V, 10% 1210
DIODE, SCHOTTKY, 30V 1A PWRDI123
SMT ZENER DIODE, 5.6V SOD-523
RES., CHIP, 806k, 1%, 0805
RES., CHIP, 53.6k, 1%, 0603
RES., CHIP, 365k, 1%, 0603
TRANSFORMER 7:1
I.C., LT8300ES5, TSOT-23
CAP., 0805
RES., 0805
MANUFACTURER/PART NUMBER
MURATA, GRM32ER72A225KA35L
AVX, 12106D107MAT2A
VISHAY/VITRAMON, VJ1210Y472KXGAT5Z
DIODES INC., DFLS130-7
DIODES INC., BZT52C5V6T-7
VISHAY, CRCW0805806KFKEA
VISHAY, CRCW060353K6FKEA
VISHAY, CRCW0603365KFKEA
WÜRTH ELECTONIK, 750312366
LINEAR TECH., LT8300ES5#PBF
OPT
OPT
