12
en | Installation
When mounting the unit on the rear side of a monitor, ensure that there is adequate
ventilation and enough clearance between both units and walls or other monitors, especially
with several monitors mounted side by side on a wall.
1.
2.
3.
4.
5.
2019.10 | v01 | F.01U.345.382
Remove the four stands on the bottom of the decoder. Retain the stands and the screws
for future usage.
Place the mounting brackets supplied as shown in the picture. Make sure that the
keyholes point in the same direction.
Fasten the mounting brackets with the screws (marked 'A' in the above figure).
Fasten the VESA mounting screws (marked 'B' in the above figure) to the monitor.
Hook the keyholes onto the VESA screw heads and slide the decoder down to secure.
Preferably, mount the decoder with connections facing downwards to ensure best
ventilation.
Installation manual
VIDEOJET decoder 7000
Bosch Securtity Systems B.V.
