- Page 1 All manuals and user guides at all-guides.com VIP X1600 XFM4 VIP-X1600-XFM4A/VIP-X1600-XFM4B Quick Installation Guide...
-
Page 2: General Information
Installation Guide", the Installation and Operating Manuals for the VIP X1600 XFM4 encoder module and the base being used, as well as the 4.0 firmware are available on www.boschsecurity.com. Bosch Security Systems Quick Installation Guide F.01U.088.580 | V4.0 | 2009.03... -
Page 3: Scope Of Delivery
Scope of Delivery – VIP X1600 XFM4A or VIP X1600 XFM4B encoder module – Two terminal blocks – Four screws for installation in the base – Quick Installation Guide F.01U.088.580 | V4.0 | 2009.03 Quick Installation Guide Bosch Security Systems... - Page 4 VIP X1600 XFM4 Unpacking | en Unpacking – Please check the delivery for completeness and integrity. – Have your device checked by Bosch Security Systems if you detect any damage! Bosch Security Systems Quick Installation Guide F.01U.088.580 | V4.0 | 2009.03...
-
Page 5: Installing And Connecting
Insert the four screws provided in the bores on the module and tighten. – After a module has been removed, you must reseal the empty slot with a cover to ensure correct air circulation. F.01U.088.580 | V4.0 | 2009.03 Quick Installation Guide Bosch Security Systems... -
Page 6: Connecting Cameras
All manuals and user guides at all-guides.com VIP X1600 XFM4 Installing and Connecting | en Connecting Cameras – Connect one camera to each, the Video In 1 socket to the Video In 4 socket. Bosch Security Systems Quick Installation Guide F.01U.088.580 | V4.0 | 2009.03... - Page 7 Secure the terminal block onto the left-hand part of the male multipoint connector. CAUTION! A maximum load of 30 V and 500 mA may be applied to the relay contact. F.01U.088.580 | V4.0 | 2009.03 Quick Installation Guide Bosch Security Systems...
-
Page 8: Serial Interface
Connect the serial-connection lines to the corresponding terminals on the 6-pin terminal block as required. – Secure the terminal block onto the right-hand part of the male multipoint connector. Bosch Security Systems Quick Installation Guide F.01U.088.580 | V4.0 | 2009.03... -
Page 9: Audio Connections
Use the Audio In and Audio Out sockets for the audio line connections. Line In Input voltage 5.5 V max., impedance 9 kOhm typ. Line Out Output voltage 3 V at 10 kOhm / 1.7 V at 16 Ohm typ. F.01U.088.580 | V4.0 | 2009.03 Quick Installation Guide Bosch Security Systems... -
Page 10: Assigning An Ip Address
Unit IP address field and click OK. The module is rebooted and the IP address is valid. Note: The module must be assigned a valid IP address and a matching subnet mask to operate on your network. Bosch Security Systems Quick Installation Guide F.01U.088.580 | V4.0 | 2009.03... -
Page 11: Testing The Configuration
Use the links at the top of the pages to navigate. NOTICE! Set the graphics card of the computer to 16-bit or 32-bit color depth. Otherwise the computer cannot display the video images. F.01U.088.580 | V4.0 | 2009.03 Quick Installation Guide Bosch Security Systems... - Page 12 All manuals and user guides at all-guides.com Bosch Security Systems Robert-Koch-Straße 100 D-85521 Ottobrunn Germany Telefon 089 6290-0 089 6290-1020 www.boschsecurity.com © Bosch Security Systems, 2009...
