mean error with 8mmHg standard deviation).

Notes on Blood Pressure Data

Any blood pressure reading can be affected by the measurement site, the position of the patient, exercise, or the
patient's physiologic condition. Environmental or operational factors which can affect the performance of the device
and/or its blood pressure reading are pacemakers and common arrhythmias such as atrial or ventricular premature
beats or atrial fibrillation, arterial sclerosis, poor perfusion, diabetes, age, pregnancy, pre-clampsia, renal diseases,
patient motion, trembling, and shivering.
Specifications SP0
Function
Saturation Normal (no motion)
Saturation Motion
Low Perfusion
Pulse Heart rate
Pulse Heart rate w/motion
Wavelength & Output Power
For more detailed information, see the instructions for use included with each device.

Specifications Temperature Sensor

Temperature accuracy
Response Time
Resolution
93-9005-00
September 1, 2016
Sensor
2
ChipOx
± 2%
(70-100%A
rms
N/A
N/A
20-300 BPM: ±3 BPM
20-300 BPM: ±3 BPM
RED: 660nm @ 3.5-4.5mW
IR: 905nm @ 3.5-4.5mW
30.1 to 42.9 °C (86.2 – 109.2 °F)
Quick Mode (Oral): ± 0.3°C
Std. Mode (Axillary/Rectal): ± 0.1°C
Direct Mode: ± 0.1°C
3-10 sec (Oral Quick Mode)
6-10 (Oral Standard Mode)
8-12 sec.(Axillary Mode)
10-14 sec.(Rectal Mode)
60-120 sec.(Direct Mode all sites)
0.1°C
Masimo M-LNCS DCI
± 2%
) (70-100%A
± 3%
(70-100%A
SpO
2
± 3% BPM
± 5% BPM
RED: 660nm @ ≤ 15mW
IR: 905nm @ ≤ 15mW
)
rms
)
rms
+/-2%
ADView 2 User Manual | 49
