Saving Measurements - ADC ADView 2 User Manual

After connecting the optional thermal printer (see Section 2 and Section 3), ensure that the green LED on the top of
the printer is lit and unblinking before printing.
Reset Print
To print the information currently displayed on the ADView 2 screen, press the print button on the top of the printer
(see diagram above).

Saving Measurements

With EMR Connectivity
Technicians may have already connected the ADView 2 to your facility's EMR system. If so, you can easily send
measurements directly to the EMR.
With the patient's current measurements displayed on the screen, press the Memory button . The EMR icon
and Check Mark icon will begin flashing.
Press the Selection Knob to send the data to the EMR. If the measurements are delivered to the EMR successfully,
you will see the EMR Message icon and the Check Mark icon blink four times.
To store the displayed measurements in the device memory without sending to the EMR:
Press the Memory Button ,
While the EMR and Check Icons are flashing, turn the Selection Knob until the X icon is displayed and then press
the Selection Knob. The measurements will be saved to the device memory only.
Without EMR Connectivity
The ADView 2 does not have to be connected to an EMR system to save measurements. You can save them to the
device's own memory. With the patient's current measurements displayed on the screen:
Press the Memory button .
All of the measurement values on the screen, the Check icon and the Memory icon will flash on and off 2
times.
The display will then return to a blank screen/shows null values, but the Check Mark icon will flash 2 more times,
this verifies the measurements are successfully stored to the device's memory.
Note: The ADView 2 does not autosave. The user must save the reading to memory after every reading.
To view results stored in memory, press the Memory Button for more than four seconds. You will see the
most recently saved measurements displayed on the screen, and can turn the Selection Knob counterclockwise to
see older measurements and then clockwise to see newer measurements.
93-9005-00 ADView 2 User Manual | 20
September 1, 2016
