Artery marker indicating proper placement – Arrow and symbol
should be placed over the brachial artery.
Cuff range indication
Device is not made with natural rubber latex
Device is not made with PVC
Class II equipment
IPX1
Protection against vertically falling drops of water
Expiration date
Single use only

Commonly Used Abbreviations

BP Blood Pressure
BPM Beats Per Minute
EMR Electronic Medical Record system
K-sounds Korotkoff sounds
MAP Mean Arterial Pressure (Not available in the U.S.)
DIA Diastolic BP
NIBP Non-Invasive Blood Pressure
SpO Percent Oxygen Saturation of Arterial Blood (hemoglobin)
2
SYS Systolic BP
2. Setting Up the ADView 2
Your ADView 2 comes ready to use. The battery and any optional modules purchased were installed prior to shipping.

Unpacking the Monitor

As you unpack your ADView 2, check to make sure you have all the proper components.
Refer to the separate packing label stating which components you received based on the options you ordered with
your device.
93-9005-00
September 1, 2016
ADView 2 User Manual | 10
