ADC Diagnostix ADSTATION Assembly Instructions

Diagnostix
ADSTATION
fter taping the specula drilling template in the desired
position on the wall, drill the 2 appropriate holes (7/32"
(5.556 mm) diameter, and 1.25" (32 mm) deep as indicated.
Push the supplied mollies as far as they will go into the
drill holes in the wall.
Put the spacer sleeves supplied (1) onto the dome (2) of
the holder (3).
The screws should now be pushed into the holes
provided (4) in the holder (3).
Place the holder on the wall so that the screws line up
with the plugs and screw them in tightly.
When the holder is firmly in place on the wall, the
casing should be attached to the holder as follows.
Place the casing on the holder such that the T-grooves
(5) lie exactly over the T-groove guides (6), the casing
should now be pushed evenly backwards until it snaps
into position. The casing should be level with the
viewing windows of the holder.
Place the lid (7) in the intended location (8).
The specula can now be filled as desired.
TM
Modular Diagnostic System
Specula Extension ssembly Instructions
TM
