Zero Button:
(Fig. 200-2)
Module Position Button(s):
crawler and the Raster Arm HT. Press to set the position to any value using the
Edit screen. When a module position is modified, the position will be modified
for all other system modes.
NOTE: This function only zeroes the number displayed on the SKOOT HT handheld
controller. It does not zero the position used in the data acquisition
instrument.
Module Rate Button(s):
selected speed mode. Press to set the maximum rate using the Edit screen.
The movement commanded by the joysticks will be limited to the indicated rate.
When a rate is modified, the rate will be modified for all other system modes.
Exit Button:
(Fig. 200-5)
screen.
Cooler Button:
(Fig. 200-6)
button will blink rapidly to indicate that the cooler is deactivated and not
pumping coolant to the scanner.
Sets the current position to zero for all modules.
Displays the current position of the
(Fig. 200-3)
Displays the current maximum rate for the
(Fig. 200-4)
Exits the jog mode and returns to the Mode Select
Press to access the cooler controls. The cooler
