Position the pivot buttons to the
5.
inside of the probe holder arms
.
(Fig. 74)
Place the probe holder arms on
6.
the yoke and tighten the arm
clamp screw and probe holder
adjustment knob
Screw the yoke to the probe
7.
holder
(Fig. 76)
TIP: When using a standard
yoke length, position
the yoke in the
threaded hole closest
to the frame bar. When
using a long yoke
length, position the
yoke in the threaded
hole furthest from the
frame bar.
5.4.1.4 Probe Holder 90° Adjustment
Remove the yoke using the
1.
supplied 3 mm hex driver
Orient the yoke to the front of the
2.
probe holder and screw the yoke
into the threaded hole provided
.
(Fig. 77)
.
(Fig. 75)
.
(Fig. 70).
PAGE 29 of 124
- Screw into threaded hole
Fig. 76
- 90° probe holder positioning
Fig. 77
