Performing A Factory Reset From Bios (Oracle Linux For Micros); Performing A Factory Reset Using The Recovery Button - Oracle MICROS 6 Series Setup Manual

On the Update and Recovery screen, click the Get started button under Reset
4.
this PC.
On the Reset your PC dialog box, click Next, click Fully clean the drive or Just
5.
remove my files, and then click Reset to finish restoring factory settings.
When the restoration is complete and the workstation reboots, you can begin the
6.
operating system setup.

Performing a Factory Reset from BIOS (Oracle Linux for MICROS)

To perform system recovery from the BIOS:
Enter the BIOS.
1.
a.
b.
c.
On the Advanced tab, use the arrow keys to select Special Configuration, and
2.
then press Enter.
Select Factory Recovery, and then press Enter.
3.
Select Enabled, and then press Enter.
4.
Press F10, select Yes, and then press Enter to save the configuration changes
5.
and exit the configuration utility. The Workstation 6 automatically restarts.
The workstation reboots and the "Entering Recovery Mode" message appears.
6.
When the message "The system will reset Oracle Linux to Factory Default......Are
7.
you sure to continue? (Y/N)" appears, type y, and then press Enter.
After the recovery process completes, the workstation reboots to the Oracle Linux
8.
for MICROS mini-setup.

Performing a Factory Reset using the Recovery Button

You can use the system recovery button to restore system settings without using a
keyboard.
Power off the workstation. Do not disconnect the power cable.
1.
Press the recovery button using any object less than 2mm in diameter. You can
2.
access the button on the Workstation 6 using an opening on the adjustable stand
mount near the DC power cable. Make sure you are not using the opening for the
security screw.
Power on the workstation. It briefly powers on, restarts, and then shows the
3.
Please Wait message below the splash screen.
On the Choose an Option screen, click Troubleshoot.
4.
For the 610:
5.
a.
Connect a USB keyboard to the Workstation 6.
Power on or restart the workstation.
Press F2 immediately after pressing the power button and before the BIOS
splash screen. You can press F2 repeatedly until the Configuration Utility
starts. If the workstation boots into the operating system without starting the
utility, restart the workstation and try again.
On the Troubleshoot screen, click Reset your PC, and then click Next.
Chapter 12
System Recovery
12-10
