SolidRF Signal Plus Manual page 3

Signal transmission loss and power level
Coverage area ability
Note: FCC regulations limit the amplification of all cell phone boosters in order to
prevent damage to the telecommunications infrastructure. Therefore, the maximum
coverage area of a booster depends on the original power level of the signal captured by
the outdoor unit.
Notice: Not recommended when outdoor signal strength is less than -110dbm(3G/1x)
or -120dBm(4G/LTE). The resulting coverage area of the boosted signal will be
prohibitively small.
Power level
at the outdoor antenna location
Strong (5 bars on the cellphone)
Medium (3~4 bars on the cellphone)
Weak (1~2 bars on the cellphone)
Coverage Area @ One Antenna
(sq. ft.)
5,000
2,500
600
Coverage Area @ Two Antenna
(sq. ft.)
8,000
4,000
1,000
3
