INTERFACING SOLUTIONS
PRODUCT FEATURES:
- 9.66" IPS display full view 2K resolution monitor with touch screen operation.
- Wide angle HD front and rear camera.
- DVR function with 32GB micro SD card included.
- Loop video recording with real-time playback.
- Access and configure your dash cam videos via the Viidure app, using cloud technology
- Split screen viewing of front and rear cameras.
- Equipped with GPS logging, automatic time zone synchronization, and an integrated compass.
- Audio recording with built-in microphone.
- Collision detection/ motion detection sensor automatically saves video in the event of a collision.
PARTS INCLUDED:
Rear View Mirror DVR
MIRROR CONTROL BUTTONS:
No.
1
USB Port
2
Video Input
3
TF Memory Card
4
Power Button
5
Touchscreen Display Panel
6
Reset Button
7
Rear Camera Input
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
R
Power Harness
7
Name
5V Power
Rear Camera Input
TF Card Slot
Long press to turn On/Off | Short press to turn off backlight
9.66" High Definition Touchscreen
System Reset
Rear View Camera
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
Rear-View Mirror with Front and Rear Camera,
Backup Camera
GPS Antenna
1 of 4
TDR-RVM32
DVR and GPS Functions
Rubber Straps
Function
rev.031224
Advertisement
Table of Contents
Related Manuals for Crux TDR-RVM32
Summary of Contents for Crux TDR-RVM32
- Page 1 Touchscreen Display Panel 9.66” High Definition Touchscreen Reset Button System Reset Rear Camera Input Rear View Camera 1 of 4 rev.031224 Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311 phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com...
- Page 2 Do not remove the TF card while the mirror/DVR is powered on to avoid damaging the TF card. rev.031224 2 of 4 Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311 phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com...
- Page 3 Customize the settings according to your preferences. select camera and adjust settings (see pg 4) rev.031224 3 of 4 Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311 phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com...
-
Page 4: Initial Settings
Format SD card (must be done before initial use) Setup Reset LCD mirror/DVR settings to factory FW Version Firmware version rev.031224 4 of 5 Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311 phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com... -
Page 5: Time And Date
4. Double-click on the thumbnail of the video you want to play to enter the video. Below are the video control buttons: Play Pause Next Previous Lock Delete Return rev.031224 4 of 4 Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311 phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com...
