Cree LS4 Installation Instructions

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety precautions
should always be followed including the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before installation.
DANGER – Risque de choc – Couper l'alimentation avant
l'installation.
2. This luminaire must be installed in accordance with the NEC or
your local electrical code. If you are not familiar with these codes
and requirements, consult a qualified electrician.
Ce produit doit être installé conformément à NEC ou votre code
électrique local. Si vous n'êtes pas familier avec ces codes et
ces exigences, veuillez contacter un électricien qualifié.
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE

TO INSTALL:

1
2
Reflector
#6-20 Self
Drilling Screws
3
#6-20 Self
Drilling Screws
1 of 2
Reflector
Reflector
LS Series
Includes: LS4 and LS8 luminaires
INSTALLATION INSTRUCTIONS
INSTALLATION
NOTE: 4-foot and 8-foot reflectors are
available for LS4 and LS8 luminaires
respectively. Images in the figures
depict LS4 with reflectors containing
apertures for illustration purposes.
The reflectors may or may not contain
apertures.
STEP 1:
Align the reflector to the luminaire as
shown in Figure 1.
STEP 2:
Mount the reflector to the luminaire
using one of the following methods:

Surface Mounting

Use (2) #6-20 Self Drilling Screws
provided with the reflector to attach
the reflector from the side as shown
in Figure 2. For LS8 luminaires attach
(4) screws as shown in Figure 3.

Suspended Mounting

Reflector can be attached from the
side as shown in Figure 2 and 3 or
from the top as shown in Figure 4
for LS4 and Figure 5 for LS8. Use
supplied #6-20 Self Drilling Screws.
LPN00278X0001A0_B
Reflector
