DPP-250 User Manual

Technical Specifications

Printing Method
Printing Speed
Print Width
Resolution
Dot Pitch
Resident Fonts
Loadable Fonts
Logo Registration
Input Buffer
Resident Barcodes
Emulation
Thermal Paper
Reliability
Compatibility
Dimensions W x D x H
Weight
Battery Capacity
Battery Life
Power Supply
Magnetic Stripe Reader
Connectivity
Operating Temperature
Relative Humidity
Storage Temperature
Relative Humidity
Line thermal dot printing
60mms/s (480 dots per second) at 8.5V
48mm/384 dots per line
203dpi (8 x 9 dot/mm)
Horizontal and vertical: 0.125mm (8 dots/mm)
A: 12 x 24 dots (32 char per line)
B: 9 x 16 dots (42 char per line)
C: 12 x 24 (32 char per line)
D: 9 x16 dots (42 char per line)
One black and white with 384 x 248 dots
128 KB (131072 bytes)
1D: EAN13, EAN8, UPC-A, UPC-E, Codebar, Code39, Code128
2D: PDF417, QR Code
ESC/POS Continuous Paper Mode
58mm +0/-1mm x 45mm diameter
60um thickness
Printing head: 50km
Printing rate: 25% maximum
Apple iOS device, Window O/S, Android O/S
6mm x 113mm x 57mm (.2" x 4.4" x 2.2")
295 grams (10.4 oz) - Without paper
350 grams (12.3 oz) - With paper
User-replaceable, rechargeable Li-ion battery
7.4V / 110mAH
~20,000 lines per charge
AC adapter: DC 9V, 1A
AC 100-240V 13.A, 50/60 Hz
(Optional) 3-track unencrypted read head, ISO7811
(Optional) Bluetooth 2.0 class 2 SPP
(Optional) Bluetooth 3.0 class 2 SPP, iPod accessory protocol
mini USB port
RS232 C 115200bps maximum serial port
Environmental
+0°C to +45°C (32°F to +113°F)
35% to 85%
-20°C to +60°C (-4°F to +140°F)
10% to 90%
Printing
Physical
Electrical
