Electrified Exit Device Installation Example - Command access MLRK1 Instructions Manual

Ceiling Tile
Re c o mm ended Powe r S u pp lie s :
All Command Access exit devices & field installable kits have been thoroughly
cycle tested with Command Access power supplies at our factory.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
Electrified Exit Device
Installation Example
Module
CAT
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
+
LOCKING
HARDWARE
-
Legend
Standard Placement
Optional Placement
