AP305C and AP305CX Hardware Guide

Console Port

The AP305C has a micro-USB Console port located on the bottom of the device.

Hardware Specifications

The following sections list radio, device, power, and environmental specifications for the AP305C and AP305CX.
Radio Specifications
Bluetooth BLE Beacon
2402 - 2480 MHz
Frequency Hopping Spread-spectrum (FHSS)
802.11a
5150-5250, 5725 - 5850 MHz operating frequency
Orthogonal Frequency Division Multiplexing (OFDM) modulation
Rates (Mbps): 54, 48, 36, 24, 12, 9, 6 with auto fallback
802.11b
2.4-2.48 GHz operating frequency
Direct-Sequence Spread-Spectrum (DSSS) modulation
Rates (Mbps): 11, 5.5, 2.1 with auto fallback
802.11g
2.4-2.48 GHz operating frequency
Orthogonal Frequency Division Multiplexing (OFDM) modulation
Rates (Mbps): 54, 48, 36, 24, 12, 9, 6 with auto fallback
802.11n
2.4-2.48 and 5.150-5.250, 5.725 - 5.850 GHz operating
frequency 802.11n modulation
Rates: MCS0 - MCS7
2x2 MIMO radio
HT20/HT40 support (HT40 is for 5 GHz only)
A-MPDU and A-MSDU frame aggregation
802.11ac
802.11ac modulation (256-QAM)
2.4 - 2.48 GHz MCS0-9, NSS=1-4
5.150-5.250, 5.725 - 5.850 GHz operating
frequency
